Summary of Contents for Klein + Hummel PRO X 6

  • Page 1 Compact Loudspeaker Installation und Bedienung Installation and Operation...
  • Page 2: Safety Instructions

    1. Safety Instructions It is absolutely essential that you read these safety instructions carefully before connecting and using this K+H product. Your safety depends on it. Furthermore, failure to follow these instructions voids the warranty. To ensure safe operation for years to come, keep these instructions in a safe place for future reference. K+H has manufactured this product in accordance with IEC 92 (SEC) 39 standards, then tested and delivered it in safe operating condition.
  • Page 3: Installation Und Operation

    PRO C28 or PRO C24. 3. Diagrams The outstanding acoustic performance of the Pro X 6 is confirmed by technical measurement as shown in the fol- lowing diagrams Figure 2: Free field frequency response Pro X 6...
  • Page 4: Warranty

    90ø 60ø 30ø 0 -3 -3 -0 0ø -6 --3 G rad -9 --6 -12 --9 -30ø -15 --12 -18 --15 -21 --18 -60ø -90ø 125.0 250.0 500.0 1000.0 2000.0 4000.0 8000.0 16000.0 f [Hz] Figure 3: Horizontal Directivity P 90ø...
  • Page 5: Technical Specifications

    6. Technical Specifications X 6 / N X 6 / H 16 Ω 83.3 Ω / 166 Ω Impedance Sensitivity 92 dB/W/m 91 dB/W/m Frequency Response ± 3 dB 90 Hz – 19 kHz 90 Hz – 19 kHz Power Taps 120 W / 60 W (selectable) Power Handling 120 W...
  • Page 6: Wichtige Sicherheitshinweise

    7. Wichtige Sicherheitshinweise Das Gerät wurde von KLEIN+HUMMEL gemäß IEC 60065 gebaut und hat unser Werk in sicherheitstechnisch einwandfreiem Zustand verlassen. Um diesen Zustand zu erhalten und einen gefahrlosen Betrieb sicherzustellen, muß der Anwender die Hinweise und Warn- vermerke beachten, die in der Bedienungsanleitung enthalten sind. Die Sicherheit, Zuverlässigkeit und Leistung des Gerätes wird von KLEIN+HUMMEL nur dann gewährleistet, wenn: •...
  • Page 7: Installation Und Inbetriebnahme

    PRO C 24 beim Einsatz des Systems empfohlen. 3. Diagramme Die überragende akustische Leistungsfähigkeit der PRO X 6 findet sich auch in den technischen Messungen bestä- tigt, die im folgenden gezeigt werden sollen. Figure 2: Freifeld Übertragungsfunktion Pro X 6...
  • Page 8: Gewährleistung

    Inanspruchnahme der Gewährleistung ist das Gerät in der Original - Verpackung kostenfrei, zusammen mit einem Fehlerbericht an unseren Vertragspartner, bei dem das Gerät gekauft wurde. KLEIN + HUMMEL gewährleistet, dass das Produkt frei von Fabrikations- und Materialmängeln ist und die zugesi- cherten Eigenschaften aufweist. Voraussetzung für die Anerkennung von Gewährleistungsansprüchen ist, dass die Mängelrüge innerhalb von 8 Tagen nach Lieferung bzw.
  • Page 9 5. Mounting Diagrams/Montageanleitung KLEIN + HUMMEL Page 8...
  • Page 10 KLEIN + HUMMEL Page 9...
  • Page 11 KLEIN + HUMMEL Page 10...
  • Page 12 KLEIN + HUMMEL Page 11...
  • Page 13: Technische Daten

    6. Technische Daten Ausführung X 6 / N X 6 / H 16 Ω 83,3 Ω / 166 Ω Impedanz Empfindlichkeit 92 dB/W/m 91 dB/W/m Frequenzbereich ± 3 dB 90 Hz – 19 kHz 90 Hz – 19 kHz Leistungsaufnahme 120 W / 60 W (schaltbar) Nennbelastbarkeit 120 W...
  • Page 14 K+H Vertriebs- und Entwicklungsgesellschaft mbH 30900 Wedemark, Germany Tel. +49 (5130) 58 48 0 Fax +49 (5130) 58 48 11 www.klein-hummel.de www.klein-hummel.com Printed 01/07 517275...
