IntesisBox ® ASCII Server - LON

Technical characteristics

Enclosure
Colour
Power
Terminal wiring (for
power supply and
low-voltage signals)
Mounting options
ASCII port
LON port
LED indicators
Push buttons
Console port
Configuration
Firmware
Functional
temperature range
Functional humidity
range
Protection
RoHS conformity
Norms and
standards
1
Not used for the moment. Reserved for future use.
2
Standard cable DB9male-DB9female 1,8 meters long is supplied with the device for connection to a PC COM port for
configuring and monitoring the device. The configuration software, compatible with Windows
This information is subject to change without notice.
Plastic, type PC (UL 94 V-0).
Dimensions: 107mm x 105mm x 58mm.
Light Grey. RAL 7035.
9 to 30Vdc +/-10%, Max.: 125mA.
24Vac +/-10% 50-60Hz, Max.: 127mA
Must use a NEC Class 2 or Limited Power Source (LPS) and SELV
rated power supply.
Plug-in terminal block for power connection (2 poles).
Per terminal: solid wires or stranded wires (twisted or with ferrule)
2
1 core: 0.5mm ... 2.5mm
2
2 cores: 0.5mm ... 1.5mm
3 cores: not permitted
Wall.
DIN rail EN60715 TH35.
1 x EIA232. (DB9 male connector DTE). SELV
1 x LON (TP-FT/10) (plug-in terminal block 2 poles). TNV-1
1 x Power.
2 x LON port activity (Tx, Rx).
2 x ASCII port activity (Tx, Rx).
1
1 x LON Service.
1
1 x LON Service.
EIA232. DB9 female connector (DCE). SELV
2
Via console port.
Allows upgrades via console port.
-25°C to +70°C
25-90% at 50ºC, non condensing
IP20 (IEC60529).
Compliant with RoHS directive (2002/95/CE).
CE conformity to EMC directive (2004/108/EC) and Low-voltage
directive (2006/95/EC)
EN 61000-6-2
EN 61000-6-3
EN 60950-1
EN 50491-3
URL http://www.intesis.com
email info@intesis.com
tel +34 938047134
2
2
®
Installation Manual
operating systems, is also supplied.
Doc. Rev. 2
4 / 5
