Installation Instructions
1.1.3 Items Supplied
Table 1.4 provides a list of items included in the 300 A and 500
A current sensor kits for D2h/D4h/D7h/D8h drives. Refer also
to Illustration 1.4.
Description
R/S/T terminal label
M10x30 machine screw with captive washer
M10 nut
Mains input terminal block
M5x12 machine screw
U/V/W terminal label
Motor terminal block
Cable retaining clip
M10 nut with captive washer
Cable clamp adapter
Power terminal mounting plate (IP21/IP54)
Power terminal mounting plate (IP20/Chassis)
Mixing fan
Mixing fan housing
EMC shield
Plastic mounting button
Motor busbar (U)
Motor busbar (V)
Motor busbar (W)
Busbar insulator sleeve
M5x16 torx screw
M8x70 screw
Cylinder busbar
Nomex tube
300 A or 500 A current sensor
Wire harness (current sensor cables)
M4x10 thread-forming screw
M5 nut
Wire harness (current sensor cables)
Multiple wire guide, not shown
Wire routing clip, not shown
M5x11 thread-cutting screw, not shown
IGBT busbar (300 A kit only)
Table 1.4 Items Supplied in 300/500 A Current Sensor Kit

1.2 Safety Information

Only qualified, Danfoss-authorized personnel are allowed to
install the parts described in these installation instructions.
Handling of the drive and its parts must be done in
accordance with the corresponding operating guide.
2
300 A/500 A Current Sensor Kit for D2h/D4h/D7h/D8h Drives
®
VLT FC Series FC 102, FC 103, FC 202, FC 302
WARNING

ELECTRICAL SHOCK HAZARD

®
VLT FC series drives contain dangerous voltages when
connected to mains voltage. Improper installation, and
installing or servicing with power connected, can cause
death, serious injury, or equipment failure.
Quantity
To avoid death, serious injury, or equipment failure:
1
•
6
6 •
1
12
•
1
1
•
6
4
2
1
WARNING
1

DISCHARGE TIME

1
The drive contains DC-link capacitors, which can remain
1
charged even when the drive is not powered. High voltage
1
can be present even when the warning LED indicator lights
3
are off. Failure to wait the specified time after power has
1
been removed before performing service or repair work can
1
result in death or serious injury.
1
•
1
•
3
3
3
3
•
3
•
1
6
•
2
1
4
1
NOTICE
6
3

ELECTROSTATIC DISCHARGE

Follow proper ESD precautions to prevent damage to
sensitive components.
Danfoss A/S © 07/2018 All rights reserved.
Only use qualified electricians for the installation.
Disconnect the drive from all power sources before
installation or service.
Treat the drive as live whenever the mains voltage
is connected.
Follow the guidelines in these instructions and local
electrical safety codes.
Stop the motor.
Disconnect AC mains and remote DC-link power
supplies, including battery back-ups, UPS, and DC-
link connections to other drives.
Disconnect or lock PM motor.
Wait for the capacitors to discharge fully. The
minimum waiting time is 20 minutes.
Before performing any service or repair work, use
an appropriate voltage measuring device to make
sure that the capacitors are fully discharged.
MI70V202
