Danfoss 176F6757 Installation Instructions

Installation Instructions

Current Sensor Cylinder Busbar Kit (D1h–D8h)
®
VLT FC Series FC 102, FC 103, FC 202, FC 302
Description
The current sensor cylinder busbar kits include all parts
required to install the cylinder busbars in D1h–D8h drives.
Each cylinder busbar is inserted through the center of a
current sensor during installation. For more information, see
the current sensor kit installation instructions listed in
Table 1.4.
Kit Ordering Numbers
Kit number
176F6517
176F6757
176F6756
Table 1.1 Ordering Numbers for Current Sensor Cylinder Busbar Kits
Items Supplied
Item
Nomex sleeve
U, V, W cylinder busbars
M6x90 screw
Cylinder busbar mounting frame
M6x16 screw
Table 1.2 Items Supplied with D1h/D3h/D5h/D6h Kit (176F6517)
Item
Nomex sleeve
U, V, W cyclinder busbars
M8x70 screw
Table 1.3 Items Supplied with D2h/D4h/D7h/D8h Kit
(176F6756/176F6757)

Safety Information

Only qualified, Danfoss authorized personnel are allowed to
install the parts described in these installation instructions.
Handling of the drive and its parts must be done in
accordance with the corresponding operating guide.
Kit description
300 A D1 LEM BB kit
300 A D2 LEM BB kit
500 A D2 LEM BB kit
Quantity
3
1 set of 3
3
1
3
Quantity
3
1 set of 3
3
Danfoss A/S © 08/2018 All rights reserved.
WARNING
ELECTRICAL SHOCK HAZARD
®
VLT FC series drives contain dangerous voltages when
connected to mains voltage. Improper installation, and
installing or servicing with power connected, can cause
death, serious injury, or equipment failure.
To avoid death, serious injury, or equipment failure:
•
Only use qualified electricians for the installation.
•
Disconnect the drive from all power sources before
installation or service.
•
Treat the drive as live whenever the mains voltage
is connected.
•
Follow the guidelines in these instructions and local
electrical safety codes.
WARNING
DISCHARGE TIME
The drive contains DC-link capacitors, which can remain
charged even when the drive is not powered. High voltage
can be present even when the warning LED indicator lights
are off. Failure to wait the specified time after power has
been removed before performing service or repair work can
result in death or serious injury.
•
Stop the motor.
•
Disconnect AC mains and remote DC-link power
supplies, including battery back-ups, UPS, and DC-
link connections to other drives.
•
Disconnect or lock PM motor.
•
Wait for the capacitors to discharge fully. The
minimum waiting time is 20 minutes.
•
Before performing any service or repair work, use
an appropriate voltage measuring device to make
sure that the capacitors are fully discharged.
MI70Z202
