Quick Start Installation & Removal Instructions
X144D-AF e-FlowMeter Included Hardware
Sensing Probe
1
Flow
2
Display
Step-By-Step X144D-AF e-FlowMeter Installation Instructions
1
flow
2
Step 2A:
Loosen Knurled Lock Nut on e-FlowMeter Assembly
3
Thumb Set Screw
Step 3A: Screw Locking Collar on straight threads. Insert
angled end of provided tool as shown, until it stops
4
Sensing
3
Cable
Complete
4
Installation Kit
Isolation Valves
CLA-VAL
Locking Collar
tape not supplied
X144D-AF e-FlowMeter
Parts List
1) Sensing Probe
2) Flow Display
3) Sensing Cable
Score
Marks
a) Insertion Tool
Step 1: Take necessary safety precautions
• Isolate the control valve using main line
isolation valves
• Bleed pressure from valve before removing
body plug
• Remove an inlet body plug
NOTE: If both inlet body tappings are used for
the pilot system, consult factory for correct
Sensor/Head Assembly
Threaded Swivel Insert
Step 2B: Pull apart. Straighten Measurement Cylinder by
hand. Set aside Sensor/Head in safe location,
protecting sensor tip
Thumb Set Screw
Step 3B: Tighten Thumb Set Screw
Step 4: Apply Teflon® tape to NPT Threads
• Check threads on valve
• Use thread chasing tool (not supplied), if
necessary
4) Installation Kit containing:
a) Insertion Tool
b) Locking Collar with
Thumb Set Screw
(a and b come assembled)
b)
Thumb Set
Screw
modification instructions.
Measurement
sensor
Cylinder
tip
Locking
Collar
