Pistol grip grease gun
Models 1132 and 1133
Date of issue
March 2015
Form number
404629F
Read manual prior to installation or use
of this product. Keep manual nearby for
future reference.
User guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1132 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lincoln 1132

  • Page 1 User guide Pistol grip grease gun Models 1132 and 1133 Date of issue March 2015 Form number 404629F Read manual prior to installation or use of this product. Keep manual nearby for future reference.
  • Page 2: Table Of Contents

    Table of contents Safety Explanation of signal words for safety Read and carefully observe these installation Safety ......instructions before installing, operating or troubleshooting the assembly.
  • Page 3: Capacity

    Use safety glasses and gloves for protec- extension or whip hose to burst. Use only tion during operation. Keep hands clear Lincoln approved hoses and follow whip of the extension during operation of the hose instructions and warnings. grease gun. Grease gun can develop high...
  • Page 4: Operating Instructions

    Operating instructions How to fill the grease How to fill a grease gun from a bulk gun with a filler pump 1 Place a grease cartridge into the container lubricant container tube. See “How to install a grease car- 1 Engage the follower rod with the follower tridge”...
  • Page 5: How To Expel Air Pocket

    How to expel air pockets 1 Unscrew the container tube approximately 1 1/2 turns from the pump head assembly. 2 Withdraw the follower rod from the con- tainer cap and engage it with the follower by rotating the follower handle. 3 While exerting light force on the follower handle, squeeze the pump handle until grease appears from the coupler or be-...
  • Page 6: Warranty

    Lincoln warrants the equipment manufac- valves, 912 series lube meters, electronic Lincoln GmbH and Co. Kg, Walldorf, tured and supplied by Lincoln to be free from Germany, for your warranty rights. lube meters (980, 981, 982 series), our uni- defects in material and workmanship for a...
  • Page 7 This page intentionally left blank.
  • Page 8 ® SKF is a registered trademark of the SKF Group. ® Lincoln is a registered trademark of Lincoln Industrial Corp. © SKF Group 2015 The contents of this publication are the copyright of the publisher and may not be reproduced (even extracts) unless prior written permis- sion is granted.

This manual is also suitable for:

1133
