USER GUIDE FOR IR3651 EVALUATION BOARD
DESCRIPTION
The IR3651 is a high voltage PWM
controller designed for high performance
synchronous Buck DC/DC applications. The
IR3651 drives a pair of external N-
MOSFETS using a programmable switching
frequency up to 400kHz allows flexibility to
tune the operation of the IC to meet system
level requirements, and synchronization
allows the simplification of system level filter
design. The output voltage can be precisely
regulated using the internal 1.25V reference
voltage
for
low
Protection functions such as under voltage
lockout and hiccup current limit are provided
to give required system level security in the
event of fault conditions.
CONNECTIONS
Rev 1.1
12/20/2006
voltage
applications.
J2: V
= 48V
IN
J3: V
= 3.3V
OUT
J4, J7: GROUND
J5: Shutdown control input
J6: Sync input
J1: External 12V supply option.
RD-0616
IRDC3651
This user guide contains the schematic and
bill of materials for the IR3651 evaluation
board. The guide describes operation and use
of the evaluation board itself.
application
information
integrated circuit is available in the IR3651
data sheet.
Evaluation Board Specifications:
V
= 48V, tolerance 10%
IN
V
= 3.3V at 10A
OUT
F
= 100kHz
S
Detailed
for
the
IR3651
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the IR3651 and is the answer not in the manual?

Questions and answers

Summary of Contents for International Rectifier IR3651

  • Page 1 USER GUIDE FOR IR3651 EVALUATION BOARD DESCRIPTION This user guide contains the schematic and The IR3651 is a high voltage PWM bill of materials for the IR3651 evaluation controller designed for high performance board. The guide describes operation and use synchronous Buck DC/DC applications.
  • Page 2: Connection Diagram

    IRDC3651 CONNECTION DIAGRAM Power Supply Load: 3.3V@ 0A to 10A Note: Ground connection pads are located on the bottom side of the circuit board. Figure 1 – Connections to IR3651 evaluation board for default configuration . Rev 1.1 RD-0616 12/20/2006...
  • Page 3 Two different MOSFET configurations can be CIRCUIT LAYOUT - TOP LAYER used: eight-pin SOIC packages on the top side The PCB is a 4-layer FR4 board. The IR3651 IC of the board or MX-packaged DirectFets on the and the associated passive components are bottom side of the board.
  • Page 4 Low Voltage Linear Regulator Components Off - board Ground Connection Pads DirectFet Positions Signal Ground Plane Heat Sink mounting area (optional) Figure 3 – Bottom layer of the IR3651 evaluation board. Rev 1.1 RD-0616 12/20/2006...
  • Page 5 IRDC3651 LAYOUT -- MID-LAYERS The two mid-layers are used primarily for Power Ground. Mid-layer 1 Mid-layer 2 Figure 3 – Internal layers of IR3651 evaluation board. Rev 1.1 RD-0616 12/20/2006...
  • Page 6 IRDC3651 Rev 1.1 RD-0616 12/20/2006...
  • Page 7: Bill Of Materials

    IRDC3651 BILL OF MATERIALS Quantity Designator Value 1 Value 2 Tolerance Description 1 Description 2 Package Source Source Part No. PWM Controller SOIC-14 IR3651 MOSFET POWER NFET DirectFET IRF6662 MOSFET POWER NFET DirectFET IRF6646 DIODE Silicon PN SOT-23 MMBD6100LT1 230mW...
  • Page 8 IRDC3651 TYPICAL Output WAVEFORMS Vin=48V, Vo=3.3V, Room Temperature, No Air Flow 0A load Cyan: V Blue: V Green: I 10A load Figure 5 – Startup waveforms Rev 1.1 RD-0616 12/20/2006...
  • Page 9 IRDC3651 TYPICAL Output WAVEFORMS Vin=48V, Vo=3.3V, Room Temperature, No Air Flow Blue: V Figure 6 – 0A to 10A Transient Green: I Figure 7 – Output Ripple, 10A load Rev 1.1 RD-0616 12/20/2006...
  • Page 10 IRDC3651 TYPICAL Output WAVEFORMS Vin=48V, Vo=3.3V, Room Temperature, No Air Flow Short Circuit : Operation and Recovery Blue: V Green: I Magenta: V Short Circuit : Detail of “Hiccup” Figure 8 – Short Circuit Response Rev 1.1 RD-0616 12/20/2006...
  • Page 11 IRDC3651 TYPICAL Output WAVEFORMS Vin=48V, Vo=3.3V, Room Temperature, No Air Flow 0A Load Blue: V Cyan: V Green: I Magenta: V 10A Load Figure 9 – Shutdown Rev 1.1 RD-0616 12/20/2006...
  • Page 12 IRDC3651 TYPICAL Output WAVEFORMS Vin=48V, Vo=3.3V, Room Temperature, No Air Flow Figure 10 – Efficiency Rev 1.1 RD-0616 12/20/2006...
  • Page 13 IRDC3651 Vin=48V, Vo=3.3V, 10A Load, Room Temperature, No Air Flow (1) IR5651 Controller (2) Inductor (3) Output Capacitors Figure 11a – Temperature Distribution, Top side (1) IRF6646 Sync-Rectifier FET (2) IRF6662 Switch FET (3) 12V linear supply resistor Figure 11b – Temperature Distribution, bottom side Rev 1.1 RD-0616 12/20/2006...
