SupIRBuck
USER GUIDE FOR IR38063 EVALUATION BOARD
DESCRIPTION
The IR38063 is a synchronous buck
converter with a PMBus interface, providing
a compact, high performance and flexible
solution in a small 5mmx7mm PQFN
package.
Key features offered by the IR38063 include
I2C/PMBus configurability of output voltage,
soft-start, input UVLO, input overvoltage
protection, output overvoltage protection,
output overcurrent protection, Power Good,
thermal protection and switching frequency.
Additionally, the IR38063 also features
enhanced line/ load regulation with feed
forward, external frequency synchronization
with smooth clocking, internal LDO, true
differential remote sensing
start-up.

BOARD FEATURES

PVin = +12V (+ 13.2V Max), No Vcc required.
• V
= +1.2V @ 0-25A
out
F
=600kHz
s
L= 0.215uH
• C
= 4x22uF (ceramic 1206) + 1x330uF (electrolytic, optional)
in
C
=7x47uF (ceramic 0805)
out
3/21/2017
TM
and pre-bias
IRDC38063-P1V2
A temperature and bias compensated output
over-current protection function is implemented
by sensing the voltage developed across the
on-resistance of the synchronous rectifier
MOSFET for optimum cost and performance.
This user guide contains the schematic and bill
of materials for the IR38063 evaluation board.
The guide describes operation and use of the
evaluation board itself. Detailed
information for IR38063 is available in the
IR38063 data sheet.
application
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the IRDC38063-P1V2 and is the answer not in the manual?

Questions and answers

Summary of Contents for International Rectifier IRDC38063-P1V2

  • Page 1: Board Features

    IRDC38063-P1V2 SupIRBuck USER GUIDE FOR IR38063 EVALUATION BOARD DESCRIPTION The IR38063 is a synchronous buck converter with a PMBus interface, providing A temperature and bias compensated output a compact, high performance and flexible over-current protection function is implemented solution in a small 5mmx7mm PQFN by sensing the voltage developed across the package.
  • Page 2 IRDC38063-P1V2 CONNECTIONS and OPERATING INSTRUCTIONS A well regulated +12V input supply should be connected to PVin+ and PVin-. A maximum of 25A load should be connected to VOUT+ and VOUT-. The inputs and output connections of the board are listed in Table I.
  • Page 3: Connection Diagram

    IRDC38063-P1V2 CONNECTION DIAGRAM PVin Vout Top View I2C / PMBus Enable Communication PGood Bottom View 3/21/2017...
  • Page 4 IRDC38063-P1V2 3/21/2017...
  • Page 5 IRDC38063-P1V2 Schematic for Transient Load set up Vout ExtLoadCtrl S3 should be in position 1-2 to enable transient load Vo_R_P Vout Vout IRF6721 OUT2 OUT1 1.5K 0.1uF 0.1uF MIC4452/SO8 I-Monitor 100p Vo_R_N 3/21/2017...
  • Page 6: Bill Of Materials

    GRM188R61A106ME69D 1 R19 7.5k 0603,1/10W,1% Rohm MCR03EZPFX7501 1 L1 215nH 0.215uH, DCR=0.29mohm Cyntec PCDC1008-R215EMO 1 M1 IRF6721 Direct Fet 30V SQ International Rectifier IRF6721STRPbF 1 R1 1.21k 0603,1/10W,1% Rohm MCR03EZPFX1211 1 R2 5.62k 0603,1/10W,1% Rohm MCR03EZPFX5621 1 R9 66.5k 0603,1/10W,1%...
  • Page 7 IRDC38063-P1V2 TYPICAL OPERATING WAVEFORMS PVin=12.0V, Vout=1.2V, Iout=0A-25A, Fs=600kHz, Room Temperature, no airflow Fig. 2: P Start up at 25A Load Fig. 3: P Start up at 25A Load , Ch , Ch , Ch :Enable , Ch , Ch Good Good Fig.
  • Page 8 IRDC38063-P1V2 TYPICAL OPERATING WAVEFORMS PVin=12.0V, Vout=1.2V, Iout=0A-25A, Fs=600kHz, Room Temperature, no airflow Fig. 8: 0.35V Prebias voltage startup at 0A load Fig. 9: Short-circuit recovery (Hiccup) at 25A load , Ch Ch2:V , Ch3:P Good Good 3/21/2017...
  • Page 9 IRDC38063-P1V2 TYPICAL OPERATING WAVEFORMS PVin=12.0V, Vout=1.2V, Iout=0A-25A, Fs=600kHz, Room Temperature, no airflow Fig. 10: Transient Response, 2.5A to 10A step (2.5A/us) , Ch Fig. 11: Transient Response, 17.5A to 25A step (2.5A/us) , Ch 3/21/2017...
  • Page 10 IRDC38063-P1V2 TYPICAL OPERATING WAVEFORMS PVin=12.0V, Vout=1.2V, Iout=0A-25A, Fs=600kHz, Room Temperature, no airflow -100 -150 -200 f/Hz TR1: Mag(Gain) TR2: Unwrapped Phase(Gain) Fig. 12: Bode Plot at 0A load Bandwidth = 83.3kHz, Phase Margin = 56.3 , Gain Margin = 10.8dB...
  • Page 11 IRDC38063-P1V2 TYPICAL OPERATING WAVEFORMS PVin=12.0V, Vout=1.2V, Iout=0A-25A, Fs=600kHz, Room Temperature, no airflow Fig.14: Efficiency versus load current Fig15: Power loss versus load current 3/21/2017...
  • Page 12 IRDC38063-P1V2 THERMAL IMAGE PVin=12.0V, Vout=1.2V, Iout=0A-25A, Fs=600kHz, Room Temperature, no airflow Fig. 16: Thermal Image of the board at 25A load IR38063: 72.9 C, inductor: 58.4 C, Ambient:26.5 3/21/2017...
  • Page 13 IRDC38063-P1V2 PMBus Command Summary PVin=12.0V, Vout=1.2V, Iout=0A-25A, Fs=600kHz, Fig. 17: PMBus Command Summary 3/21/2017...
  • Page 14 IRDC38063-P1V2 Quick Start: PowIRCenter GUI Connecting devices Start PowIRCenter & Step 1 Connect USB Dongle Detect attached demoboards Step 2 USB Dongle connected USB Dongle NOT detected Press “Auto Populate Devices” button to detect boards connected to USB dongle...
  • Page 15 IRDC38063-P1V2 Quick Start: PowIRCenter GUI Navigation: Accessing Different Views Access different views Step 3 Access Config File Menu Click device name to access save / load configuration files menu. Click channel to access PMBus commands for selected channel Access Board View...
  • Page 16 IRDC38063-P1V2 Quick Start: PowIRCenter GUI PMBus Commands Select Command for Selected Channel Select command Click the command from pull down List in right panel. Enable / Disable Channel (Command: OPERATION) PMBus Command Screen Ensure the channel enable is set high on board.
