IRU3073 EVALUATION BOARD USER GUIDE
INTRODUCTION
The IRU3073 controller IC is designed to provide a low
cost synchronous Buck regulator for on-board DC to DC
converter for multiple output applications.
The outputs can be programmed as low as 0.8V for low
voltage applications.
Selectable over-current protection is provided by using
external MOSFET's on-resistance for optimum cost and
performance.
This device features a programmable frequency set from
200KHz to 400KHz, under-voltage lockout for all input
supplies, an external programmable soft-start function
as well as output under-voltage detection that latches off
the device when an output short is detected.
INPUT/OUTPUT CONNECTIONS
The following is the input/output connections:
Inputs:
JP3: Input (+5V), Gnd
JP1: Input (+12V)
Outputs:
JP4: V
(+2.5V), Gnd
OUT1
JP2: V
(+1.6V), Gnd
OUT2
Note: For proper operation, +5V supply should ramp up first.
Rev. 1.0
06/30/03
SPECIFICATION DATA
Switcher:
Linear
V
= 5V
Regulator:
IN
V
= 2.5V
V
OUT1
I
= 8A
(from switch)
OUT1
DV
= 50mV
V
OUT
F
= 200KHz
I
S
OUT2
The connection points is shown in Figure 1. Connect the
power supply cables according to this figure, minimize
wire lengths to reduce losses in the wire. Test point J1
provides easy connections for the oscilloscope voltage
probe to monitor the output voltage.
www.irf.com
IRDC3073EVAL
Supply Voltage:
V
= V
= 12V
CC
C
= 2.5V
IN
= 1.6V
OUT2
= 2A
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the IRDC3073EVAL and is the answer not in the manual?

Questions and answers

Summary of Contents for International Rectifier IRDC3073EVAL

  • Page 1 IRDC3073EVAL IRU3073 EVALUATION BOARD USER GUIDE INTRODUCTION SPECIFICATION DATA The IRU3073 controller IC is designed to provide a low Supply Voltage: Switcher: Linear cost synchronous Buck regulator for on-board DC to DC = 12V = 5V Regulator: converter for multiple output applications.
  • Page 2: Connection Diagram

    IRDC3073EVAL CONNECTION DIAGRAM +12V Power Supply 1A Supply Load2 Load1 Power Supply 0 - 10A 10A Supply Figure 1 - Connection diagram of evaluation-board for IRU3073. www.irf.com Rev. 1.0 06/30/03...
  • Page 3 IRDC3073EVAL LAYOUT The four layers for IRU3073 evaluation board are shown sistors are tied to the output voltage at the point of regu- in Figures 2.1-2.4. The layout is designed both for direct lation. FET package and SOIC package for power MOSFETs.
  • Page 4 IRDC3073EVAL LAYOUT Figure 2.2 - Middle layer 1. Figure 2.3 - Middle layer 2. Figure 2.4 - Bottom layer. www.irf.com Rev. 1.0 06/30/03...
  • Page 5 IRDC3073EVAL SCHEMATIC Rev. 1.0 www.irf.com 06/30/03...
  • Page 6: Bill Of Material

    IRDC3073EVAL BILL OF MATERIAL Ref Desig Description Value Part# Manuf Web site (www.) Q1,Q2 MOSFET IRF7832 irf.com MOSFET IRLR2703 Controller IRU3073CQ Schottky Diode BAT54 Inductor 1mH, 5.6A DO3316P-102 Coilcraft coilcraft.com Inductor 3.3mH, 17A DO5022P-332HC Coilcraft C1,C2A,B,C Cap, Poscap 47mF, 16V...
  • Page 7: Typical Operating Characteristics

    IRDC3073EVAL TYPICAL OPERATING CHARACTERISTICS Figure 1 - Normal condition at no load. Figure 3 - Gate signals when SS pin pulls low. Ch1: HDrv Ch1: HDrv Ch2: LDrv Ch2: LDrv Ch4: Inductor Current Figure 2 - Gate signals when SS pin pulls low.
  • Page 8 IRDC3073EVAL TYPICAL OPERATING CHARACTERISTICS Figure 6 - Output Shorted at start-up. Figure 8 - Load Transient Response Ch1: V (PWM Section). Ch2: I Figure 7 - Output Shorted at start-up. Figure 10 - Load Transient Response Ch1: V (PWM Section).
