TECHNICAL DATA
& SERVICE MANUAL
INDOOR UNIT: MCAF72R5TA-
SPLIT SYSTEM AIR CONDITIONER
Model No.
MCAF72R5TA-
MCAF92R5TA-
MCAF122R5TA-
MCAF92R5TA-
MCAF122R5TA-
Product Code No.
387104015
387104016
387104017
0.8180.354.0
04/2004
