COP-INVERTER-ARGO.qxd 6-02-2004 16:07 Pagina 1
Pub. OI-85264180689000
OPERATING INSTRUCTIONS • NOTICE D'UTILISATION
BEDIENUNGSANLEITUNG • ISTRUZIONI D'USO
INSTRUCCIONES DE USO
This air conditioner uses the new refrigerant R410A.
Save These Instructions! • Conserver ce mode d'emploi
Bewahren Sie bitte diese Bedienungsanleitung auf
Conservate queste istruzioni • Guarde estas instrucciones
Split air conditioner system • Climatiseurs split
Split-klimagerät • Condizionatore d'aria split system
Acondicionador de aire de consola partida sistema split
MCAF94MR5IAA
MCAF124MR5IAA
MCAF184MR5IAA
MCAF244MR5IAA
02/2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MCAF184MR5IAA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Technibel MCAF184MR5IAA

Summary of Contents for Technibel MCAF184MR5IAA

  • Page 1 BEDIENUNGSANLEITUNG • ISTRUZIONI D’USO INSTRUCCIONES DE USO This air conditioner uses the new refrigerant R410A. MCAF94MR5IAA MCAF124MR5IAA MCAF184MR5IAA MCAF244MR5IAA Save These Instructions! • Conserver ce mode d’emploi Bewahren Sie bitte diese Bedienungsanleitung auf Conservate queste istruzioni • Guarde estas instrucciones Split air conditioner system •...

  • Page 2: Features

    Features This air conditioner is equipped with cooling, heating, and drying functions. Details on these functions are provided below; refer to these descriptions when using the air conditioner. • Microprocessor Controlled Operation • Air Sweep Control The interior compartment of the remote control This function moves a flap up and down in the unit contains several features to facilitate air outlet, directing air in a sweeping motion...

  • Page 3: Table Of Contents

    Contents Page Features ......................2 Product Information ..................3 Alert Symbols ....................3 Installation Location ..................4 Electrical Requirements .................. 4 Safety Instructions ..................4 Names of Parts ....................5 Using the Remote Control Unit ..............11 Operation with the Remote Control Unit ............ 12 1.

  • Page 4: Installation Location

    Installation Location • We recommend that this air conditioner be installed properly by qualified installation technicians in accordance with the Installation Instructions provided with the unit. • Before installation, check that the voltage of the electric supply in your home or office is the same as the voltage shown on the nameplate. •...

  • Page 5: Names Of Parts

    Names of Parts Air intakes INDOOR UNIT Air outlet Remote control unit Drain hose Refrigerant tubes OUTDOOR UNIT Air outlet This illustration is based on the external view of a standard model. NOTE Consequently, the shape may differ from that of the air conditioner which you have selected.
  • Page 6 Unit Display and Operation Selector MCAF244 MCAF94/124/184 INDOOR UNIT Operation INDOOR UNIT selector Operation selector TIMER OPERATION lamp lamp SERVICE TIMER OPERATION REMOTE CONTROL lamp lamp lamp recelver IMPORTANT Avoid using radio equipment such as mobile phone near (within 1 m) the remote control receiver. Some radio equipment may cause malfunction of the unit.
  • Page 7 Remote Control Unit (Display) Displayed when setting temperature in automatic operation Displayed when transmitting data elector Displayed when indoor unit sensor is in use Displayed when setting temperature Displayed when setting timer Symbols (1) Operation mode (5) ECONOMY ......AUTO ........(6) High power operation ...

  • Page 8: Remote Control Unit

    Remote Control Unit Sensor Transmitter (Cover closed) Display ON/OFF operation button HIGH POWER button 1 HR. TIMER button Temperature setting buttons (TEMP .) ECONOMY button OFF TIME setting button ON TIME setting button MODE selector button Return button FAN SPEED selector button Advance button FLAP button SET button...
  • Page 9 Remote Control Unit (continued) No display : The timer does not operate. ON TIME/OFF TIME setting buttons : The air conditioner stops at the set time. : The air conditioner starts at the set time. : The air conditioner stops and starts, or starts and stops, at the set times every day.
  • Page 10 Remote Control Unit (continued) ADDRESS switch • Change the address switch to prevent mixing of signals from remote control units when two Sanyo air conditioners are installed next to each other. Normally, the address switch is set to A. When switching the adress, take the steps listed below.

  • Page 11: Using The Remote Control Unit

    Using the Remote Control Unit How to Install Batteries 1. Slide the cover in the direction indicated by the arrow and remove it. 2. Install two AAA alkaline batteries. Make sure the batteries point in the direction marked in the battery compartment.

  • Page 12: Operation With The Remote Control Unit

    Operation with the Remote Control Unit 1. Automatic Operation STEP 2 STEP 3 STEP 1 STEP 1 Press the MODE selector button and select (AUTO). STEP 2 Press the ON/OFF button and switch the air conditioner ON. STEP 3 Press the temperature setting buttons (TEMP .). The air conditioner starts operating after automatically selecting the type of operation —whether heating, drying (dehumidifying) or cooling—that suits the conditions in the room, and automatically adjusting the temperature, fan speed and airflow direction.

  • Page 13: Manual Operation

    Operation with the Remote Control Unit (continued) As shown in the figure below, the automatic selection of the operating modes is determined by the indoor temperature and outside air temperature. Temperature setting Indoor temperature (standard) Approx. Approx. Approx. 27°C 15°C 22°C Cooling Approx.
  • Page 14 Operation with the Remote Control Unit (continued) STEP 1 Press the MODE selector button and select the desired mode. → For heating operation For dehumidifying operation → → For cooling operation STEP 2 To start the air conditioner, press the ON/OFF operation button.

  • Page 15: Adjusting The Fan Speed

    Operation with the Remote Control Unit (continued) 3. Adjusting the Fan Speed A. Automatic Simply set the FAN SPEED selector button to the position. B. Manual If you want to adjust fan speed manually during operation, just set the FAN SPEED selector button as desired. [ , or 4.
  • Page 16 Operation with the Remote Control Unit (continued) A. In Cooling and DRY When the ECONOMY mode is selected, the air conditioner Mode: ( and ) automatically raises the temperature setting 1 °C when 60 minutes have passed after the selection was made. This enables you to save energy without sacrificing comfort.

  • Page 17: Special Remarks

    Special Remarks Power failure • In the event of power failure, the unit will stop. Though the power is during operation resumed, the unit will not restart automatically. Press the ON/OFF operation button and restart the unit again. Clicking Sound •...

  • Page 18: Setting The Timer

    Setting the Timer 1. How to set the present (Example) To set to 10:30 pm. time Operation Indication 1. Press the CLOCK button three The time indication alone blinks. times. 2. Press the Advance, Return ( , ) The time can be set in 1-minute button until PM 10:30 is increments.
  • Page 19 Setting the Timer (continued) NOTE • The timer can be programmed while the unit is operating or while it is stopped. • A timer program is canceled after the timer has operated. So the timer should be set every time programming operation is to be performed.
  • Page 20 Setting the Timer (continued) 4. How to set DAILY ON/ (Example) To start operation at 7:10 am. and stop the air conditioner at OFF REPEAT timer 11:00 am. 7:10 am. 11:00 am. Present time Operation Indication 1. Set the timer ON/OFF times as The present time 10:30 pm.

  • Page 21: Setting The 1-Hour Off Timer

    Setting the 1-Hour OFF Timer 1. 1-Hour OFF Timer This function causes the unit to operate for one hour and then stop, regardless of whether the unit is on or off when this button is pressed. indicator in the display indicates that this function is operating. Setting the 1-Hour OFF Timer: Regardless of whether the unit is operating or stopped, press the 1 HR.

  • Page 22: Tips For Energy Saving

    Setting the HIGH POWER Operation (continued) NOTE Concerning HIGH POWER During a heating operation • The room is heated for 15 minutes by warm air which has a slightly operations higher temperature than usual. • When the HIGH POWER button is pressed during a defrosting operation, the unit enters the HIGH POWER operating mode upon completion of the defrosting operation.

  • Page 23: Adjusting The Airflow Direction

    Adjusting the Airflow Direction 1. Horizontal The horizontal airflow can be adjusted by moving the vertical vanes with your hands to the left or right. When the humidity is high, the vertical vanes should be in the front CAUTION position during the cooling or dehumidifying operation. If the vertical vanes are positioned all of the way to the right or left, condensation may begin to form around the air vent and drip down.

  • Page 24: Operation Without The Remote Control Unit

    Operation without the Remote Control Unit If you have lost the remote control unit or it has trouble, follow the steps INDOOR UNIT below. 1. When the air conditioner is not running If you want to turn on the air conditioner, switch the operation selector to the OFF position, and then to the ON position.
  • Page 25 Care and Cleaning (continued) Anti-Mold Filter The anti-mold filter behind the air intake grille should be checked and cleaned at least once every two weeks. How to remove the 1. Grasp both ends anti-mold filter of the air intake Air intake grille grille and pull it out and up.
  • Page 26 Care and Cleaning (continued) Air Cleaning Filter The air cleaning filter removes dust and dirt from the air, and reduces odors and smoke from tobacco. This air cleaning filter cannot remove harmful gases or vapors nor ventilate air in the room. You must open doors or windows frequently when you use gas or oil heating appliances.

  • Page 27: Troubleshooting

    Troubleshooting If your air conditioner does not work properly, first check the following points before requesting service. If it still does not work properly, contact your dealer or service center. Trouble Possible Cause Remedy Air conditioner does not run 1. Power failure. 1.
  • Page 28 COP-INVERTER-ARGO.qxd 6-02-2004 16:07 Pagina 2 In order to carry on a constant improvement, our products can be modified without prior notice. Per garantire un costante miglioramento dei nostri prodotti, ci riserviamo di modificarli senza preavviso. Par souci d’amélioration constante, nos produits peuvent être modifiés sans préavis. Unsere Produkte werden laufend verbessert und können Vorankündigung abgeändert Werden.
