Technibel MCAF188R5I Installation Instructions Manual

Cool/dry/heat

Hide thumbs Also See for MCAF188R5I:

Technical & service manual (107 pages)

,

Installation instructions manual (21 pages)

,

Installation instructions manual (57 pages)

Table of Contents

Advertisement

Quick Links

Download this manual

06-154 MCAF186 - 246R5I ENG

Please Read Before Starting .................................. 2

1.

GENERAL .......................................................... 3

1-1. Tools Required for Installation (not supplied)

1-2. Accessories Supplied with Unit

1-3. Optional Copper Tubing Kit

1-4. Type of Copper Tube and Insulation Material

1-5. Additional Materials Required for Installation

2.

INSTALLATION SITE SELECTION ................... 4

2-1. Indoor Unit

2-2. Outdoor Unit

3.

HOW TO INSTALL THE INDOOR UNIT ............. 6

3-1. Remove the Rear Panel from the Unit

3-2. Make a Hole

3-3. Install the Rear Panel on the Wall

3-4. Remove the Grille to Install the Indoor Unit

3-5. Shape the Indoor Side Tubing

3-6. Wiring Instructions

3-7. Recommended Wire Length and Diameter

3-8. Wiring Instructions for Inter-unit Connections

3-10. Drain Hose

4.

HOW TO INSTALL THE OUTDOOR UNIT ....... 16

4-1. Wiring Instructions for the Outdoor Unit

5.

REFRIGERANT TUBING .................................. 17

5-1. Use of the Flaring Method

5-2. Flaring Procedure with a Flare Tool

5-3. Caution before Connecting Tubes Tightly

5-4. Connecting Tubing between Indoor and

5-5. Insulation of Refrigerant Tubing

5-6. Taping the Tubes

5-7. Finishing the Installation

6.

AIR PURGING................................................... 19

I Air Purging with a Vacuum Pump (for Test Run)

I Basic Functions of the Service Valves

85264190272000 03/2006

3/15/06

11:04 AM

Page a

This air conditioner uses the new refrigerant R410A.

Contents

INSTALLATION INSTRUCTIONS

- Split system air conditioner -

Page

Combine indoor and outdoor units only as listed

below.

Indoor Unit

MCAF188R5I

MCAF248R5I

Power Source:

50 Hz, single-phase, 220 - 240 VAC

Be sure to read the yellow instruction sheet

attached to the outdoor unit for models using the

new refrigerant R410A.

7.

REMOTE CONTROL UNIT INSTALLATION

POSITION ......................................................... 23

7-1. Mounting on a Wall

8.

ADDRESS SWITCH .......................................... 24

8-1. Address Setting of the Remote

9.

ELECTRIC WIRING SYSTEM........................... 25

NOTE

The illustrations are based on the typical appearance

of a standard model. Consequently, the shape may

differ from that of the air conditioner that you are

installing.

COOL / DRY/ HEAT Model

Model Combinations

Outdoor Unit

GRF186R5I

GRF246R5I

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the MCAF188R5I and is the answer not in the manual?

Questions and answers

Summary of Contents for Technibel MCAF188R5I

Page 1: Table Of Contents
Combine indoor and outdoor units only as listed IMPORTANT! below. Please Read Before Starting ........2 Indoor Unit Outdoor Unit GENERAL ............3 MCAF188R5I GRF186R5I 1-1. Tools Required for Installation (not supplied) MCAF248R5I GRF246R5I 1-2. Accessories Supplied with Unit 1-3. Optional Copper Tubing Kit Power Source: 1-4.
Page 2: Important
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 2 IMPORTANT! Please Read Before Starting When Installing… This air conditioning system meets strict safety and operat- ing standards. As the installer or service person, it is an …In a Ceiling or Wall important part of your job to install or service the system so Make sure the ceiling/wall is strong enough to hold the it operates safely and efficiently.
Page 3: General
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 3 1. General 6. Sabre saw or key hole saw This booklet briefly outlines where and how to install 7. Hacksaw the air conditioning system. Please read over the 8. Core bits entire set of instructions for the indoor and outdoor 9.
Page 4: Additional Materials Required For Installation
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 4 1-5. Additional Materials Required for Installation Indoor unit Refrigeration (armored) tape Insulated staples or clamps for connecting wire (See local codes) Putty Refrigeration lubricant Clamps or saddles to secure refrigerant tubing Drain hose 2.
Page 5: Outdoor Unit
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 5 2-2. Outdoor Unit Exhaust fan AVOID: Hot air Heat source heat sources, exhaust fans, etc. (Fig. 4) damp, humid or uneven locations. Outdoor unit position the outdoor unit in a protected location where snow will not blow into it.
Page 6: How To Install The Indoor Unit
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 6 3. How to Install the Indoor Unit 3-1. Remove the Rear Panel from the Unit (1) Remove and discard the set screw on the rear panel. (Fig. 6) (2) Press the 2 marks on the frame cover and dis- engage the stationary tabs from the frame.
Page 7: Install The Rear Panel On The Wall
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 7 (4) Using a sabre saw, key hole saw or hole-cutting NOTE drill attachment, cut a hole in the wall. See Table 4 Hole should be made at a slight downward slant to the and Fig.
Page 8: Remove The Grille To Install The Indoor Unit
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 8 3-4. Remove the Grille to Install the Indoor Unit Air intake grille Grille Basically, these models can be installed and wired without removing the grille. If access to any internal part is needed, follow the steps as given below.
Page 9: Shape The Indoor Side Tubing
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 9 3-5. Shape the Indoor Side Tubing (1) Arrangement of tubing by directions Frame a) Right or left tubing Cut out the corner of the right/left frame with a hacksaw or the like. (Figs. 20 and 21) Left tubing outlet b) Right-rear or left-rear tubing...
Page 10: Recommended Wire Length And Diameter
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 10 3-7. Recommended Wire Length and Diameter Regulations on wiring diameter differ from locality to locality. For field wiring requirements, please refer to your local elec- trical codes. Carefully observe these regulations when carry- ing out the installation.
Page 11: Wiring Instructions For Inter-Unit Connections
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 11 3-8. Wiring Instructions for Inter-unit Connections (1) Grasp both ends of the air intake grille, and remove it by opening towards the front and pulling Cover towards you. (2) Remove the screw on the right side cover plate and open the cover.
Page 12 06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 12 Loose wiring may cause the WARNING terminal to overheat or result in unit malfunction. A fire hazard may also exist. There- fore, be sure all wiring is tightly connected. When connecting each power wire to the correspond- ing terminal, follow the instructions “How to connect wiring to the terminal”...
Page 13: Mounting
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 13 3-9. Mounting (1) To install the indoor unit, mount the indoor unit onto the 2 tabs on the upper part of the rear plate. (2) Hold down the air discharge outlet and press the lower part of the indoor unit until it clicks to securely fasten to the 2 tabs on the lower part of the rear plate.
Page 14 06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 14 I Left-side tubing (1) Lead the tubing and drain hose through the wall, Rear panel allowing sufficient length for connection. Then bend the tubing using a tube bender to make the Hole in wall attachment.
Page 15: Drain Hose
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 15 To unmount indoor unit Press the 2 marks on the lower part of the indoor unit and unlatch the tabs. Then lift the indoor unit and unmount. (Fig. 42) 3-10. Drain Hose a) The drain hose should be slanted downward to the outdoors.
Page 16: How To Install The Outdoor Unit
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 16 4. How to Install the Outdoor Unit for GRF186 First refer to Section 2. Installation Site Selection. Outdoor unit NOTE The drain hole at the bottom of the outdoor unit was not plugged at the time of factory shipment.
Page 17: Refrigerant Tubing
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 17 5. Refrigerant Tubing Deburring Before After 5-1. Use of the Flaring Method Many of the conventional split system air conditioners employ the flaring method to connect refrigerant tubes which run between indoor and outdoor units. In this method, the copper tubes are flared at each end and connected with flare nuts.
Page 18: Connecting Tubing Between Indoor And Outdoor Units
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 18 5-4. Connecting Tubing between Indoor and Torque wrench Outdoor Units a) Tightly connect the indoor side refrigerant tubing Spanner extended from the wall with the outdoor side tubing. Indoor unit (Fig.
Page 19: Air Purging
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 19 6. Air Purging Indoor unit Air and moisture remaining in the refrigerant system have undesirable effects as indicated below. Therefore, they must be purged completely. pressure in the system rises operating current rises cooling (or heating) efficiency drops Outdoor unit...
Page 20 06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 20 (5) With the vacuum pump still running, close the “Lo” knob of the manifold valve. Then stop the vacuum 90° (1/4 turn) Narrow tube pump. (6) With the hex wrench, turn the valve stem on the Hex wrench narrow tube service valve counter-clockwise by 90 degrees (1/4 turn) for 10 seconds, and then turn the...
Page 21 06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 21 How to Test Run the Air Conditioner After turning on power to the air conditioner, use the remote controller and follow the steps below to con- duct the test run. (1) Set the remote controller in Test Run mode.
Page 22: I Basic Functions Of The Service Valves
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 22 Basic Functions of the Service Valves The basic functions of the service valves are given in Table 8 below. Table 8 Narrow Tube Service Wide Tube Service Action Valve (2-Way) Valve (3-Way) O-ring Valve cap...
Page 23: Remote Control Unit Installation Position
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 23 7. Remote Control Unit Installation Position The remote control unit can be operated from either a non-fixed position or a wall-mounted position. To ensure that the air conditioner operates correctly, do not install the remote control unit in the following places: In direct sunlight...
Page 24: Address Switch
06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 24 8. Address Switch 8-1. Address Setting of the Remote Control Unit The address can be set in order to prevent interfer- ence between remote controllers when two indoor units are installed near each other. The address is nor- mally set to “A.”...
Page 25 06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 25 9. Electric Wiring System...
Page 26 06-154 MCAF186 - 246R5I ENG 3/15/06 11:04 AM Page 26...
Page 27 06-155 MCAF186 - 246R5I FRA 3/15/06 1:45 PM Page 28 R.D. 28 Reyrieux BP 131 - 01601 Trévoux C EDEX France Tel. (33) 04.74.00.92.92 - Fax (33)04.74.00.42.00 http:/ / www.technibel.com...
