DREAMS Amelia Bed Assembly Instructions Manual

Advertisement

Quick Links

Amelia Bed
Assembly Instructions
Before you
Start, here
is some
helpful advice
1. We suggest you spend a short time reading through this leaflet and then
follow the simple step by step instructions.
2. If you follow the instructions carefully the end result should be worth the
effort.
3. Do not discard any of the packaging until you have checked that you
have all the parts and the pack of fittings.
4. Assemble this product on a carpet.
5. To ensure an easier assembly, we strongly advise that all fittings are only
finger tightened during initial assembly. Only upon completion of the.
assembly should all fixing points be fully tightened.
6. We recommend a periodic check on all fixing points to make sure they
remain fully tightened.
7. Keep glue and fittings out of children's reach.
In the unlikely event that this product has missing or
damaged parts, please call 08703 333612 to obtain spares.
1 of 8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Amelia Bed and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DREAMS Amelia Bed

  • Page 1 Amelia Bed Assembly Instructions Before you 1. We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions. Start, here 2. If you follow the instructions carefully the end result should be worth the is some effort.
  • Page 2 Component parts contained in the box PARTS 2 of 8...
  • Page 3 Fittings contained in the box Please note: The assembly kit is contained in three packs: two kits are in box number 2, one kit is in box 4 Fittings -040-00770 16 PCS-040-00767 16PCS-040-00768 4 PCS-040-00769 4 PCS 6 PCS-040-00771 4 PCS-040-00772 8 PCS-040-00773 4 PCS-040-00774 QTY :12 PCS -040-00775...
  • Page 4 ASSEMBLY 1) Fit wood dowels J into holes in the STEP 1 ends of side rails 2 and 3. Fit wood dowels I into the holes in the end of the centre rail 7. 2) Screw metal cam studs B into headboard panel 6.
  • Page 5 ASSEMBLY STEP 3 1) Assemble headboard 1 by threading screws F through washers D and the holes in headboard 1 into the corresponding holes in side rails 2 and 3. Tighten using Allen key K STEP4 1) Further secure headboard 1 to the headboard panel 6 by threading screw L through the holes both in headboard 1 and headboard panel...
  • Page 6 ASSEMBLY Construct the slat frame as follows: STEP 5 1) Bolt head/foot bars 10 to the centre bar 12 using screws G, washers C and nuts P as shown. 2) Secure the side bars 11 by threading screws G into the corresponding holes in the head/foot bars 10.
  • Page 7 ASSEMBLY STEP 1) Secure the support arms T to the side rails, by threading screws W and the side rails and into JCN nuts U. 1) Two people carefully lower the STEP slat frame onto the support arms T. Secure by threading screws E through the holes in the slat frame and the corresponding holes in the support arms T.
  • Page 8 Customer Information Solid wood /real wood veneers This product has been finished using natural materials. As living material you may notice some variation in the grain and colour shade between the different component parts. Unlike a synthetic or man-made material which has a uniform finish , a feature of natural wood is its variation in grain and colour .We wish to reassure you that this is quite normal , and is not the result of any manufacturing fault.
