Pulsar AWZ 101 Manual page 5

www.pulsar.pl
Battery circuit protection SCP and reverse
polarity connection
Over-discharge protection UVP
Technical output:
- TAMPER - indicates enclosure opening
F fuse
BAT
F fuse
MAIN
Mechanical specifications (tab. 4).
Enclosure dimensions
Fixing
Fitting battery
Net/gross weight
Enclosure
Closing
Connectors
Operation safety (tab.5).
Protection class PN-EN 60950-1:2007
Degree of Protection PN-EN 60529: 2002 (U)
Electrical strength of insulation:
- between input and output circuits of the PSU (I/P-O/P)
- between input circuit and PE protection circuit (I/P-FG)
- between output circuit and PE protection circuit (O/P-FG)
Insulation resistance:
- between input circuit and output or protection circuit
Operating specifications (tab.6).
Operating temperature
Storage temperature
Relative humidity
Vibrations during operation
Impulse waves during operation
Direct insulation
Vibrations and impulse waves during transport
Fig. 4. Current-voltage characteristics of the PSU.
AWZ101
the PTC resettable fuse, manual restart (the fault requires
disconnection of the DC output circuit)
F2A - current limitation, F
element replacement required)
U<10 V (± 5%) – disconnection (- BAT) of the battery,
- a micro switch, NC contacts (enclosure closed),
0,5A@50V DC (max.)
F2A / 250V
T315mA / 250V
200 x 230 x 80+8 (WxHxD) [mm] (+/- 2)
175 x 203 x Φ 6 x 4szt (WxH)
7Ah/12V (SLA) max.
165x100x75mm (WxHxD) max
1,8 / 2,1 kg
Steel plate DC01, thickness: 0,8mm, colour: RAL 9003
Cheese head screw (at the front)
Outputs: Ф0,51÷2,5 (AWG 24-12)
Battery outputs: BAT: 6,3F-0,75, 19cm
I (first)
IP20
3000 V/AC min.
1500 V/AC min.
500 V/AC min.
100 MΩ, 500V/DC
-10ºC...+40ºC
-20ºC...+60ºC
20%...90%, without condensation
unacceptable
unacceptable
unacceptable
PN-83/T-42106
5
GREY POWER
fuse (in case of a failure, fuse-
BAT
H
W
D
