- Page 1 Final Trim Size: 8.268 x 11.693 in. (210 x 297 mm) FINAL FOR PRINT NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 1 Tuesday, June 12, 2018 9:16 AM USER GUIDE 26.6 Cu. Ft. French Door Refrigerator NS-RFD26SS9 Before using your new product, please read these instructions to prevent any damage.
-
Page 2: Table Of Contents
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 2 Tuesday, June 12, 2018 9:16 AM Contents Introduction ..................3 IMPORTANT SAFETY INSTRUCTIONS . -
Page 3: Introduction
NS-RFD26SS9 26.6 Cu. Ft. French Door Refrigerator Introduction Congratulations on your purchase of a high-quality Insignia product. Your NS-RFD26SS9 represents the state of the art in refrigerator design and is designed for reliable and trouble-free performance. IMPORTANT SAFETY INSTRUCTIONS CAUTION... -
Page 4: Grounding Requirement
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 4 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator 21 Children should be supervised to ensure that they do not play with your refrigerator. 22 If the power cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly qualified person, in order to avoid a hazard. -
Page 5: Features
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 5 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 Features Package contents • 26.6 cu. ft. French door refrigerator • 1/4" extension tubing (1) (inside the refrigerator drawer) • Coupler (1) (inside the refrigerator drawer) • Clips (2) (inside the refrigerator drawer) •... -
Page 6: Interior
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 6 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator Interior Note: The illustrations shown in this user guide are only for reference. The actual product may differ slightly. Top cover Display Water filter Refrigerator Door rack Shelf Water... -
Page 7: Exterior
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 7 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 Exterior Refrigerator doors Handles Freezer door www.insigniaproducts.com... -
Page 8: Control Panel
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 8 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator Control panel The control panel is located at the top of the inside of your refrigerator. The first time you connect your refrigerator to power, all the icons light for three seconds and a buzzer sounds. When you open the refrigerator compartment door, the control panel lights. -
Page 9: Setting Up Your Refrigerator
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 9 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 ITEM DESCRIPTION Lights when the refrigerator compartment is in Super Cool mode. See Using Super Cool to speed refrigerator cooling on page 23. Lights when your refrigerator is in Energy Saving mode. See Using the Energy Saving mode on page 23. -
Page 10: Finding A Suitable Location
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 10 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator Finding a suitable location • Place your refrigerator on a floor that is strong enough to support your refrigerator when it is fully loaded. • Do not install your refrigerator on carpeting or a rug. •... -
Page 11: Providing Room For Doors To Open
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 11 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 Providing room for doors to open Make sure that you have enough room in front of your refrigerator to swing the doors open. 35.8" (91 cm) 59.1" (150 cm) Providing the correct power source Check your power outlet. -
Page 12: Leveling Your Refrigerator
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 12 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator Leveling your refrigerator Leveling your refrigerator is important. If you do not level your refrigerator during installation, the doors may not close or seal correctly which can cause cooling, frost, or moisture problems. CAUTION: The rollers are not casters. -
Page 13: Removing The Refrigerator Doors (Optional)
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 13 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 Removing the refrigerator doors (Optional) If the opening to the installation area you chose is too narrow for your refrigerator to pass through, remove the doors and drawers, then move your refrigerator sideways into the area. - Page 14 NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 14 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator 4 Using both hands, open each refrigerator compartment door more that 90°, then lift the door up and off. >90° www.insigniaproducts.com...
- Page 15 NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 15 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 5 Use a 5 mm Allen wrench to remove the four hex head hinge bolts (two per hinge) on the lower left and rights sides of your refrigerator, then remove the hinges.
- Page 16 NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 16 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator 7 Lift the ice storage box up and out. Ice storage box www.insigniaproducts.com...
- Page 17 NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 17 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 8 Lift the upper freezer drawer up from the rails and out. Upper freezer drawer 9 Lift the lower freezer drawer up and out. Lower freezer drawer www.insigniaproducts.com...
- Page 18 NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 18 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator 10 Remove the four screws that secure the support frame. Support frame www.insigniaproducts.com...
-
Page 19: Connecting The Water Supply
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 19 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 11 Pull the bottom of freezer compartment door away from the support frame, then lift the door up and out. 12 Move your refrigerator into its final position, then re-install the drawers and doors by reversing these steps. - Page 20 NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 20 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator You will need the following tools and parts (not included): Phillips screwdriver Ferrule 1/4" (sleeve) (1) compression 1/4" saddle-type Flat-blade screwdriver nut (1) shutoff valve (1) 1/2"...
- Page 21 NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 21 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 3 Connect the 1/4" extension tubing (included) to the shutoff valve. Shutoff valve Compression nut Extension tubing Packing nut Outlet valve Ferrule (sleeve) 4 Turn the main water supply back on, then turn on the shutoff valve and flush out the tubing until the water runs clear.
-
Page 22: Using Your Refrigerator
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 22 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator Using your refrigerator CAUTION: Never close the refrigerator or freezer doors while the shelves, drawers, or telescopic slides are extended. It may damage both them and your refrigerator. Switching between Fahrenheit and Celsius To toggle between Celsius and Fahrenheit on the display, press and hold both the Super Cool and Energy Savings buttons for three seconds. -
Page 23: Using The Water Dispenser
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 23 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 Using the water dispenser The water dispenser is located inside the left side of the refrigerator compartment. 1 Open the left refrigerator door. 2 Position you glass about 1.5" (4 cm) under the dispenser, then push the lever with the glass. -
Page 24: Using The Door Baskets
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 24 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator Using the door baskets CAUTION: Do not put too many heavy items in the door baskets. You may break the baskets. Your refrigerator has six door baskets designed to store canned liquids, bottled drinks, and packaged food. To remove or relocate a door basket: 1 To remove a basket, remove all items from the basket, lift it, then pull it out of the door. -
Page 25: Adjusting The Glass Shelves
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 25 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 Adjusting the glass shelves The glass shelves inside the refrigerator compartment are adjustable. 1 To remove a shelf, tilt up the front of the shelf, then lift it vertically up and out of your refrigerator. -
Page 26: Maintaining Your Refrigerator
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 26 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator Maintaining your refrigerator Your refrigerator is designed for year-round use with only minimal cleaning and maintenance. When you first receive it, wipe the cabinet with a mild detergent and warm water, then wipe dry with a dry cloth. Do this periodically to keep your refrigerator looking new. -
Page 27: Defrosting The Freezer Compartment
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 27 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 Defrosting the freezer compartment Tip: To avoid standing water when you defrost, place some towels on the floor in front of your refrigerator. Although the freezer compartment automatically defrosts, a layer of frost may occur on the compartment’s interior walls if the freezer is opened frequently or kept open too long. - Page 28 NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 28 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator To drink the freshest and cleanest water from your refrigerator, change the filter on time. 1 Shut off the water supply, then turn off the water shutoff valve on your refrigerator. 2 Turn the old water filter about 1/4 turn counter-clockwise, then pull out the filter.
- Page 29 NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 29 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 4 Pull out the water filter tray, then empty the tray. Dry around the filter opening, then put the tray back in. 5 Insert the new water filter into the water filter holder.
-
Page 30: Replacing The Led Light
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 30 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator 6 While turning the new filter clockwise, push it all the way into the holder until it locks into place. 7 Turn on the shutoff valve and the water supply, then run water through the dispenser until the water runs clear (about five minutes). -
Page 31: Moving Your Refrigerator
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 31 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 Moving your refrigerator 1 Unplug your refrigerator from the power outlet. 2 Remove all food. 3 Securely tape down all loose items inside your refrigerator. 4 Tape the door shut. -
Page 32: Troubleshooting
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 32 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator Troubleshooting CAUTION: Do not try to repair your refrigerator yourself. Doing so invalidates the warranty. PROBLEM SOLUTION • Make sure that your refrigerator is securely plugged into a working outlet. •... - Page 33 NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 33 Tuesday, June 12, 2018 9:16 AM NS-RFD26SS9 PROBLEM SOLUTION • When you open the refrigerator door, warm air rushes inside. When you close the door, the warm air rushes to the condenser which causes a vacuum. This The refrigerator door is hard to causes the door to be hard to open for about 10 to 15 seconds after closing.
-
Page 34: General
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 34 Tuesday, June 12, 2018 9:16 AM 26.6 Cu. Ft. French Door Refrigerator Specifications General Exterior dimensions (W × D × H) 36 × 33.6 × 70 in. (91.4 × 85.4 × 177.8 cm Glass shelf (W × D × H) 15.5 ×... -
Page 35: One-Year Limited Warranty
During the Warranty Period, if the original manufacture of the material or workmanship of the Product is determined to be defective by an authorized Insignia repair center or store personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. - Page 36 For product inquiries, please contact us with the information below: 1-877-467-4289 www.insigniaproducts.com INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A. ©2018 Best Buy. All rights reserved.
