- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S FUSION SMALL SINGLE STUD FLAT PANEL MOUNT Spanish Product Description /German Product Description Portuguese Product Description Italian Product Description STMS1U...
-
Page 2: Important Safety Instructions
The STMS1U mounts are designed to be ACCESSORY: AN ACCESSORY is the secondary Chief mounted to: product which is attached to a primary Chief product, and may • a bare 8" thick concrete or 8"x8"x16" concrete block have a component attached or setting on it. -
Page 3: Installation Instructions
Installation Instructions STMS1U DIMENSIONS 1.08 27.5 6.00 152.3 6.00 152.4 12.00 304.8 0.34 6.31 160.2 49.9 12° 4.50 114.2 2.95 3.94 75.0 100.0 SHOWN WITH 100 mm ADAPTER (INCLUDED) DIMENSIONS: INCHES [MILLIMETERS]... - Page 4 Installation Instructions STMS1U LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 5: Tools Required For Installation
STMS1U Installation Instructions TOOLS REQUIRED FOR INSTALLATION 3/16" x 10" 1/8" 7/32" (5.5mm) Wood Stud (included) (included) 3/8" (9.5mm) Concrete PARTS Universal Hardware Kit H (4) G (4) F (4) E (4) C (4) A (4) B (4) D (4) -
Page 6: Installing To A Wood Stud Wall
Hang mount (X), aligning upper mounting slot over lag bolt. Place one slotted washer (Q) over flanged lag bolt. (See The STMS1U mounts are designed to be mounted to a bare 8" Figure 2) thick concrete or 8"x8"x16" concrete block wall with NO drywall;... - Page 7 Installation Instructions STMS1U Installing to a Concrete Wall Locking Rails (Optional) Determine the center of the TV screen, and where it should Lock rails into place using two 1/4-20 x 3/4" set screws (T) on be located on the wall.
- Page 8 STMS1U Installation Instructions Attaching Interface Brackets to Screen (without adapter) NOTE: For 100x100mm and 75x75mm hole patterns, the 100x100 adapter must be installed. For all other hole (MA) (MB) patterns, proceed ahead to step 2. (100x100mm and 75x75mm hole patterns ONLY) Use four #10-24 X 3/8"...
- Page 9 Installation Instructions STMS1U Attaching Screen to Wall Mount NOTE: Interface brackets (Y and Z) cannot be installed inside the two upright brackets of wall mount! Both interface bracket must be installed to the outside of the upright brackets. (See Figure 8)
- Page 10 STMS1U Installation Instructions Tilt Locking Screen Interface Brackets (Optional) The interface brackets (Y and Z) allow from -2° to 12° tilt, and Lock screen interface brackets onto mount rails using one 3/8-16 x 3/4" set screw (U) on each interface bracket. (See can be locked at 0°, 6°...
- Page 11 Installation Instructions STMS1U...
- Page 12 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
