Description of LEDs on the Remote 2C
The Remote 2C has the following LEDs:
LED
State
Power
ON
(green)
OFF
Global Fault
ON
(orange)
RPS
OFF
(green)
ON
Flashing
10Base-T
ON
(green)
100VG
ON
(green)
OFF
In Use
ON
(green)
OFF
Act(ivity)
Flickering
(green)
Link OK
On
(green)
Off
Flashing
Slot Specific
LEDs (4)
Slot Fault
On
(orange)
Off
Meaning
The Remote 2C is receiving power.
The Remote 2C is not receiving power.
One or both slot modules experienced a hardware problem.
The Remote 2C is not receiving power from the HP J2962A Redundant Power Supply (RPS).
The Remote 2C is receiving power from the connected RPS.
An error has occurred on the RPS connected to the Remote 2C. See the documentation
provided with the RPS for troubleshooting.
The corresponding module is connected to a 10Base-T or Ethernet
network.
The corresponding module is connected to a 100VG network.
The port is not connected to any network or no slot module is present.
The module is inserted in the slot correctly.
A module is not inserted in the slot or is inserted incorrectly.
Shows the amount of activity for the network connected to a port.
The LAN connected to the RJ-45 connector is providing link beat (Ethernet) or training was
successful (100VG).
Link beat is not detected.
The port is partitioned because of excessive collisions.
See the manual for that module for LED behavior.
This module has experienced a failure. See Troubleshooting on page 13.
The normal state. Indicates that there are no fault conditions on the module. Refer to the
four slot specific LEDs for more troubleshooting information.
11
