2. If you are not using an RPS, plug the included power cord into the Remote 2C's power cord
receptacle and into an AC power source as shown below.
3. After power has been applied to the Remote 2C, it executes a self test. Check the LEDs during
self test. Self test lasts up to 3 seconds for the Remote 2C and then each module executes its
own self test simultaneously. The self test time for each module varies depending on which
modules are installed. The Internet Router Module requires approximately 60 seconds. If both
modules are installed, self test time is still approximately 60 seconds because the modules self-
test simultaneously:
During Self Test:
All LEDs are ON for the Remote 2C. Then some of the Remote 2C's LEDs turn off while the
modules are tested.
After Self Test:
LEDs For:
Front of Remote 2C
Internet Router Module
Internet Router Module
Slide-In Label
10
LEDs that are ON
Power
RPS (if connected)
In Use for Slot A and/or Slot B
10Base-T or 100VG
Power
Sys Ok
LAN 10Base-T
100VG
Link OK
LAN Activity
Power receptacle
on the back of the
Remote 2C
