QuickSpecs
Overview
The HP StorageWorks SAN Switch 2/16-EL is a 2 Gb transfer speed Fibre Channel SAN Fabric Switch featuring the optional ability
to trunk or aggregate the throughput of up to four inter switch ports. With sixteen ports, users will be able to create up to four 8 Gb
Trunked ISLs between two or more similar 2 Gb switches. It also features optional SFP (Small-Form-Factor-Pluggable) connectors,
which allow for higher port density than was available using GBICs. The higher speed, coupled with the optional Trunking feature,
will allow users to install these switches in pairs for use as high speed backbone devices for joining SAN islands with little to no
performance degradation. The increased performance of these switches also is appropriate where high throughput needs exist, such
as video streaming, intensive on-line transaction processing (OLTP), and medical imaging. The SAN Switch 2/16-EL combines 1 Gb
and 2 Gb Fibre Channel throughput with new features that greatly enhance switch operation.
The SAN Switch 2/16-EL scales to a maximum of 4 switches in a SAN fabric. An optional upgrade license increases switch scaling to
full SAN configurations.
Key Features and Benefits
Key Features and Benefits
Key Features and Benefits
Key Features and Benefits
Reduced Total Cost of Ownership (TCO) for SAN Infrastructure
Reduced Total Cost of Ownership (TCO) for SAN Infrastructure
Reduced Total Cost of Ownership (TCO) for SAN Infrastructure
Reduced Total Cost of Ownership (TCO) for SAN Infrastructure
Enables storage consolidation, simplified management of data center SAN environment
Interoperability with the more than 1 MILLION port HP SAN Switch installed base
Interoperability with the more than 1 MILLION port HP SAN Switch installed base
Interoperability with the more than 1 MILLION port HP SAN Switch installed base
Interoperability with the more than 1 MILLION port HP SAN Switch installed base
Highest integration with HP Open View Storage Area Manager via:
Highest integration with HP Open View Storage Area Manager via:
Highest integration with HP Open View Storage Area Manager via:
Highest integration with HP Open View Storage Area Manager via:
SAN Switch API
SAN Switch element managers
HP StorageWorks Fabric Manager
Broadest range of compatibility with SAN products
Broadest range of compatibility with SAN products
Broadest range of compatibility with SAN products
Broadest range of compatibility with SAN products
Multi-vendor server and storage environment
Widest range of HP SAN solutions
Backward compatible with previously installed 1 Gb and 2 Gb SAN Switches
HP StorageWorks SAN Switch 2/16-EL B-Series Family
HP StorageWorks SAN Switch 2/16-EL B-Series Family
HP StorageWorks SAN Switch 2/16-EL B-Series Family
HP StorageWorks SAN Switch 2/16-EL B-Series Family
DA - 11363
Worldwide — Version 17 — June 24, 2005
Page 1

Advertisement

   Also See for HP StorageWorks 2/16-EL

   Related Manuals for HP StorageWorks 2/16-EL

   Summary of Contents for HP StorageWorks 2/16-EL

  • Page 1

    The HP StorageWorks SAN Switch 2/16-EL is a 2 Gb transfer speed Fibre Channel SAN Fabric Switch featuring the optional ability to trunk or aggregate the throughput of up to four inter switch ports. With sixteen ports, users will be able to create up to four 8 Gb Trunked ISLs between two or more similar 2 Gb switches.

  • Page 2

    Switch 2/16-EL Switch 2/16-EL Switch 2/16-EL Switch 2/16-EL HP StorageWorks SAN Switch 2/16-EL Full SAN scaling license HP StorageWorks SAN Switch 2/16-EL B-Series Family HP StorageWorks SAN Switch 2/16-EL B-Series Family HP StorageWorks SAN Switch 2/16-EL B-Series Family HP StorageWorks SAN Switch 2/16-EL B-Series Family DA - 11363 Worldwide —...

  • Page 3

    An ASIC based capability in the 2 Gb family of switches that enables new applications and features. The Frame Filtering Frame Filtering switch now has the ability to "view" the first 64 bytes of the Fibre Channel frame. At this time, Frame Filtering enables advanced capabilities such as Advanced Zoning and Advanced Performance Monitoring.

  • Page 4: Product Highlights

    Each 2-Gb switch needs its own license. The switch operating system views the trunk as a single, high bandwidth resource (up to 8 Gb) when routing connections between switches. Connections are load-balanced across the individual links, which comprise the logical trunk group.

  • Page 5

    Public Key Infrastructure (PKI)-based authentication, and 128-bit encryption of the switch's private key used for digital signatures. With its flexible design, Secure Fabric OS enables organizations to customize SAN security to meet specific policy requirements. In addition, Secure Fabric OS works in conjunction with Advanced Zoning to further secure access to the SAN, simplify storage management, and reduce provisioning time.

  • Page 6

    Hardware Warranty - One-year on-site warranty, 8x5, next business day response, installation not included. Saleable software carries its own warranty, see below. Software Warranty - HP warrants only that the software media will be free of physical defects for a Software Warranty Software Warranty Software Warranty period of ninety (90) days from delivery.

  • Page 7

    QuickSpecs Service and Support, HP Care Pack and Warranty Information HP Care Pack Information HP Care Pack is defined as an upgrade to the product warranty attribute, available for a specific HP Care Pack Information HP Care Pack Information HP Care Pack Information duration and hours of coverage.

  • Page 8

    NOTE: NOTE: Requires correct Host Bus Adapter. Not all Operating Systems Supported. NOTE: HP StorageWorks SAN Switch 2/16-EL B-Series Family HP StorageWorks SAN Switch 2/16-EL B-Series Family HP StorageWorks SAN Switch 2/16-EL B-Series Family HP StorageWorks SAN Switch 2/16-EL B-Series Family...

  • Page 9: Configuration Information

    StorageWorks SAN Switch StorageWorks SAN Switch StorageWorks SAN Switch StorageWorks SAN Switch Optional license which increases switch scaling from four switches to full SAN 2/16-EL Full SAN scaling 2/16-EL Full SAN scaling 2/16-EL Full SAN scaling 2/16-EL Full SAN scaling...

  • Page 10: Technical Specifications

    Certified maximum Certified maximum http://h18000.www1.hp.com/products/storageworks/san/documentation.html Interoperability Interoperability Interoperability Interoperability SAN Switch 8, SAN Switch 16, SAN Switch 8-EL, SAN Switch 16-EL, SAN switch 2/32, Core Switch 2/64 Performance Performance Performance Performance 2.125 Gb/s line speed, full duplex Switch core Switch core...

  • Page 11

    The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
