- Page 1 USER GUIDE Gemini 120A Series ® Coffee Brewing System READ AND SAVE THESE INSTRUCTIONS NOTICE TO INSTALLER: Please leave this booklet with the machine.
-
Page 2: Table Of Contents
..........................................................................................................................................................................Contact Information Wilbur Curtis Co., Inc. 6913 Acco Street | Montebello, CA 90640 US Phone: 323-837-2300 | Toll Free: 800-421-6150 Email: csrassistance@wilburcurtis.com | Web: www.wilburcurtis.com . - 4:00 . PT Email: techsupport@wilburcurtis.com... -
Page 3: Fs23
KEY FEATURES/SPECIFICATIONS/SYSTEM REQUIREMENTS FS23 Key Features • Brews automatically in 12 or 24 cup increments per cycle. • Automatic timer allows brewing of 24 cups without brew basket reloading. • Hot water faucet lets you draw steaming hot water for tea or soups — even during brewing. •... -
Page 4: Is2
INSTRUCTIONS could result in personal injury or void the warranty. • This appliance is designed for commercial use. Any service other than cleaning and preventive maintenance should be performed by an authorized Wilbur Curtis service technician. • serviceable parts inside. - Page 5 IMPORTANT SAFEGUARDS CE Requirements • This appliance must be installed in locations where it can be overseen by trained personnel. • • • • This appliance must not be cleaned by water jet. • instruction concerning use of the appliance in a safe way and if they understand the hazards involved. •...
-
Page 6: Ii2
INSTALLATION INSTRUCTIONS WARNING: WARNING: properly grounded. NOTICE: SPECIFICATIONS section. IMPORTANT: Installation Instructions Installation Requirements • A secure surface capable of supporting the weight of the appliance. • For units without an attached cord set: Appropriately sized, UL listed, grounding type power cable to meet enough •... -
Page 7: Ii16
INSTALLATION INSTRUCTIONS II16 Installation NOTICE: Failure to follow installation instructions may result in damage to the unit. Leveling WARNING: Use the leveling legs to level the brewer only. Do not use them to adjust brewer height. Do not extend them higher than necessary. Position the brewer on the counter top. - Page 8 INSTALLATION INSTRUCTIONS II16 Connect the Brewer Wiring, 220 Volt Units (cont.) Tighten the strain relief and replace the front cover and brew deck. Connect the power cable wires to the terminals in the junction box. See the ELECTRICAL SCHEMATIC for the power supply requirements.
- Page 9 INSTALLATION INSTRUCTIONS II16 18 Replace the top cover. Reconnect the power cord and turn on the toggle switch on the back of the unit. The water in the tank will begin to heat. Depending on the incoming water temperature and the electrical minutes to reach the factory set operating temperature.
-
Page 10: Oi20
OPERATING INSTRUCTIONS OI20 Brewing Instructions WARNING - TO AVOID SCALDING, AVOID SPLASHING. Keep body parts clear of the brewer during ® NOTICE - Do not use IntelliFresh satellites on non-IntelliFresh brewers. ® The Gemini brewer is factory preset for optimal performance. The brewer should be ON. -
Page 11: Ci1
CLEANING INSTRUCTIONS WARNING: HOT SURFACES - To avoid injury, allow the brewer and dispenser(s) to cool before cleaning. NOTICE - Do not use cleaning liquids, compounds or powders containing chlorine (bleach) or corrosives. USE OF THESE PRODUCTS WILL VOID THE WARRANTY. Cleaning The Brewer - Daily WARNING: DO NOT immerse the brewer in water or any other liquid. -
Page 12: Ci3
CLEANING INSTRUCTIONS Cleaning the Satellite (Daily) WARNING: DO NOT immerse the satellite in water or any other liquid. Do not place the satellite in a dishwasher. Placing the satellite in a dishwasher will void the warranty. Cleaning the Liner Prepare a mild solution of detergent and warm water. Remove the satellite from the brewer and remove the lid. - Page 13 CLEANING INSTRUCTIONS Cleaning the Faucet Parts and Site Gauge (cont.) 10 Air Dry - Allow all parts to thoroughly air dry. 11 Reassemble - When dry, reassemble the handle/ bonnet. Hand tighten the handle/bonnet onto the top of the faucet assembly. Reinstall the site gauge (if applicable).
- Page 14 ROUGH-IN DRAWINGS RD29 GEM-120A - Single Coffee Brewer 20.00 in [50.8 cm] 9.13 in [23.2 cm] 27.13 in [68.9 cm] 21.75 in [55.2 cm] 6.50 in 0.50 in [16.5 cm] 4.50 in [1.3 cm] [11.4 cm] 3.50 in 16.50 in [22.9 cm] [8.9 cm] GEM-120A, ROUGH-IN DRAWING...
- Page 15 IP38 GEM-120A - Main Chassis - Exploded View Water tank assemblies: - see section IP39 for domestic units - see section IP40 for dual voltage units - see section IP41 for export units 22A* *GEM-120A-10 GEM-120A, ILLUSTRATED PARTS/RECOMMENDED PARTS 032718E...
- Page 16 WHITE EPDM 70 SHORE WC-29044-101 SLEEVE, OVERFLOW WC-2401-P ELBOW 3/8 NPT X 1/4 FLARE PLTD 1 GEM-120A-10, 2 GEM-120A-63, 3 GEM-120A-30 e Units built after 4/2018. b Units built before 05/15/17. f Units built between 4/2012 and 4/2018. g Units built before 4/2012.
- Page 17 ILLUSTRATED PARTS/RECOMMENDED PARTS IP39 WC-5466 - Tank Assembly WC-5466 - Tank Assembly - Parts List ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION WC-5466 TANK, COMPLETE GEM-120A/C500AP GUARD, SHOCK/HEATING ELEMENT FOR SINGLE WC-4394 HEATING ELEMENT WC-37008 KIT, TANK LID ROUND (INCLUDES GASKET) THERMOSTAT, MANUAL RESET 120/ 240 VAC 25A WC-523 WC-37317...
- Page 18 ILLUSTRATED PARTS/RECOMMENDED PARTS IP40 WC-54133 - Tank Assembly WC-54133 - Tank Assembly - Parts List ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION WC-54133 TANK, COMPLETE GEM-120A 120/220V DV THERMOSTAT, HI LIMIT HEATER CONTROL DPST WC-522 277V 40A WC-37008 KIT, TANK LID ROUND (INCLUDES GASKET) WC-37365...
- Page 19 ILLUSTRATED PARTS/RECOMMENDED PARTS IP41 WC-5466-30 - Tank Assembly WC-5466-30 - Tank Assembly - Parts List ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION WC-5466-30 TANK, COMPLETE GEM-120A THERMOSTAT, HI LIMIT HEATER CONTROL DPST WC-522 277V 40A WC-37008 KIT, TANK LID ROUND (INCLUDES GASKET) WC-37365 KIT, FITTING TANK INLET WC-37317...
- Page 20 ELECTRICAL SCHEMATICS ES46 GEM-120A-10 GEM-120A-10, ELECTRICAL SCHEMATIC 122916NC...
- Page 21 ELECTRICAL SCHEMATICS ES47 GEM-120A-63 ELECTRICAL RATING TABLE # of Voltage Amps Wa s Hertz # of Tank Tank Element Warmer Element Model Conductor Phase Elements Ra ng W/V g W/V Wires 15.0 1775 1600W/120V GEM-120A-63 100W/120V 120/220 10.0 2100 2000W/220V 120/240 2380 GEM-120A-63, ELECTRICAL SCHEMATIC...
- Page 22 ELECTRICAL SCHEMATICS ES48 GEM-120A-30 ELECTRICAL RATING TABLE # of Voltage Amps Wa s Hertz # of Tank Tank Element Warmer Element Model Phase Conductor Elements Ra ng W/V Ra ng W/V Wires 2175 GEM-120A-30 50/60 2000W/220V (1X) 100W/220V 10.3 2380 10.8 2590 GEM-120A-30, ELECTRICAL SCHEMATIC...
- Page 23 TROUBLESHOOTING GUIDE TG16 WARNING: Electric Shock Hazard - Scald and Burn Hazard - Troubleshooting Guidelines • • Use this troubleshooting guide along with the appropriate ELECTRICAL SCHEMATIC. • Valve Test Procedure in either direction No Power - No Control Panel Lights Come On Water Not Hot Enough...
- Page 24 TROUBLESHOOTING GUIDE TG16 Water Does Not Heat At All Tank Does Not Fill • Water Not Hot Enough • • ELECTRICAL SCHEMATIC Water Heats More Slowly Than Usual Water Tank Does Not Fill IMPORTANT:...
- Page 25 TROUBLESHOOTING GUIDE TG16 Brewer Does Not Start When Brew Button is Pressed (Control Panel Lights Are On) Water Tank Does Not Fill Setting the Brew Timer, Dispenser Not Filled To Normal Level During Brewing (Coffee Too Strong) SPECIFICATIONS sure that the spray head is correctly aligned and that the tubing is routed properly to allow for maximum water Setting The Brew Timer Water Too Hot (Boiling or Excessive Steaming) IMPORTANT:...
- Page 26 TROUBLESHOOTING GUIDE TG16 Warmer Does Not Heat NOTE Setting the Brew Timer Programming Control board button (red) Front panel Programming...
- Page 27 Return Merchandise Authorization (RMA): All returned equipment must be properly re-packaged in the original carton and received by Curtis within 45 days following the issuance of a RMA. NO UNITS OR PARTS WILL BE ACCEPTED WITHOUT A RETURN MERCHANDISE AUTHORIZATION (RMA).
