Menu Parameters

The Main menu organizes the avail-
able transmitter parameters into
three categories:
• Radio
• Audio
• Utilities
Main
Radio
Menu Map
Radio
F1 Freq
F2 Freq
F2 Ctrl
Power
Output
Audio
O set
Mute
Tone Gen
Level
Utilities
Device ID
Lock
Talk Sw
Marker
Battery
About
Reset All
Tips for Editing Menu
Parameters
• To access the menu options from
the home screen, press O . Use
the arrow buttons to access addi-
tional menus and parameters.
• A menu parameter will blink when
editing is enabled
• To increase, decrease or change
a parameter, use the arrow
buttons
• To save a menu change, press O
• To exit a menu without saving a
change, press X
Radio Menu
F1 Freq
Press the enter button to enable editing of a group (G:) channel (C:) or frequency (MHz). Use the arrow buttons to
adjust the values. To edit the frequency, press the O button once to edit the first 3 digits, or twice to edit the second 3
digits.
F2 Freq
Press the enter button to enable editing of a group (G:) channel (C:) or frequency (MHz). Use the arrow buttons to
adjust the values. To edit the frequency, press the O button once to edit the first 3 digits, or twice to edit the second 3
digits.
F2 Ctrl
Turns F2 (F2 Freq) On or Off.
Power
Higher power settings can extend the range of the transmitter.
Output
- On: RF signal is active
- Mute: RF signal is inactive
Audio Menu
Offset
Adjust Offset level to balance mic levels when using two transmitters for frequency diversity or when assigning
multiple transmitters to receiver slots. Adjustment range: -12 dB to +21 dB.
Mute
When enabled, the power switch is configured as a mute switch for the audio:
- Power switch on: audio signal on
- Power switch off: audio signal muted
Tone Gen
Transmitter will generate a continuous test tone:
- Freq: The tone can be set to 400 Hz or 1000 Hz.
- Level: Allows for adjustment of the output level of the test tone.

Utilities Menu

Device ID
Assign a device ID of up to 9 letters or numbers.
Locks
- None: The controls are unlocked
- Power: The power switch is locked
- Menu: The menu parameters are locked
- All: The power switch and menu parameters are locked
Locks the transmitter controls and power switch.
Link Info
Displays the following information about the link between a transmitter and receiver:
- Not Linked: The transmitter is not linked to a receiver
- Linked: The transmitter is linked to a receiver. Select Unlink? to free the transmitter from the receiver link.
- Unlinked: The transmitter is not linked to a receiver
SL Test
ShowLink test tool to measure the boundaries of ShowLink coverage.
Talk Sw
Indicates the status of the talk switch.
Marker
When enabled, press the enter button to drop a marker in Wireless Workbench.
Battery
Displays battery information:
- Battery: The chemistry type of for the installed battery (Shure Rechargeable, Alkaline, Lithium, NiMH)
- Bars: Indicates the number of bars displayed
- Time: Battery runtime
- Charge: Percentage of charge capacity
- Health: Percentage of current battery health
- Cycle Count: Record of the number of charging cycles for the installed battery
About
Displays the following transmitter information:
- Model Displays the model number
- Band Displays the tuning band of the transmitter
- FW Version Installed firmware
- HW Version Hardware version
- Serial Num Serial number
Reset All
Restores all transmitter parameters to factory settings.
