ADXFD2 Handheld Transmitter
ADX series transmitters deliver impeccable audio quality and RF performance, and are equipped with ShowLink
adjustments and interference avoidance. This transmitter additionally features Frequency Diversity for seamless audio in even the most challenging en-
vironments. Light-weight aluminum construction, AA or SB920 rechargeable power options (with dockable charging).
Features
Performance
• 184 MHz tuning range
• Frequency Diversity enables simultaneous transmission on two inde-
pendent frequencies to ensure seamless, uninterrupted audio for mis-
sion-critical applications. Single carrier mode is available if Frequency
Diversity is not required.
• 20 Hz to 20 kHz range with flat frequency response
• Automatic input staging optimizes gain setting
• Diversity ShowLink-enabled for remote transmitter control and automat-
ic interference avoidance
• AES 256-bit encryption-enabled for secure transmission
• >120 dB, A-weighted, System Gain @ +10
• Dante Output: >130dB, A-weighted, System Gain @ +10
• 100 meter (300 feet) line-of-sight operating range
• Selectable modulation modes optimize performance for spectral effi-
ciency or audio quality:
- Standard – optimal coverage, low latency
- High density – dramatic increase in max system channel count
• Switchable Power Levels in single carrier mode = 2/10/50 mW (region
dependent)
• Power Level 2x20 mW in frequency diversity mode (region dependent)
• Built-in tone generator and RF markers to facilitate range-testing

Included Components

SB920 Shure Rechargeable
Battery
Zipper Bag
Euro-Threaded Adapter
Swivel Adapter, black
Choice of (1) of the following Shure
microphone cartridges:
SM58 (RPW112)
BETA 87C (RPW122)
BETA 58A (RPW 118)
KSM8 Black (RPW174)
KSM9HS Black (RPW186)
95A25763
95B2313
31B1856
90F4046
KSM9 Nickel (RPW188)
BETA 87A (RPW120)
KSM9 Black (RPW184)
KSM8 Nickel (RPW170)
KSM9HS Nickel (RPW190)
Design
• Interchangeable Shure microphone cartridges
• Backlit LCD with easy to navigate menu and controls
• Rugged metal construction
• Menu and power lockout
Power
• Shure SB920 rechargeable batteries for up to 9 hours of runtime, preci-
sion metering, and zero memory effect
• AA-compatible battery sled available
• External charging contacts for docked charging

Optional Accessories

Radome Color ID Kit for AD2
Battery Contact Cover for AD2
Microphone stand adapter
Optional Shure microphone cartridges:
SM58 (RPW112)
SM86 (RPW114)
SM87A (RPW116)
BETA 58A (RPW118)
BETA 87A (RPW120)
BETA 87C (RPW122)
VP68 (RPW124)
KSM9 Nickel (RPW188)
KSM9HS Nickel (RPW190)
KSM9 Black (RPW184)
KSM9HS Black (RPW186)
4
remote control for real-time parameter
®
WA617M
WA618
WA371
