440
Maxi Sky
Instructions for Use
001.16000.33.EN rev.6
February 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Maxi Sky 440 and is the answer not in the manual?

Questions and answers

Related Manuals for Arjo Maxi Sky 440

Summary of Contents for Arjo Maxi Sky 440

  • Page 1 Maxi Sky Instructions for Use 001.16000.33.EN rev.6 February 2010...
  • Page 2 ARJO International AB.© ARJO International 2010 ARJO products are patented or patent pending. Patent information is available by contacting ARJO International Our policy is one of continuous development, and we therefore reserve the right to make technical alterations without notice. The content of this publication may not be copied either whole or in part without the consent of...

  • Page 3: Table Of Contents

    Table of Contents General Information ....................5 Foreword ......................5 Service and Support ..................5 Manufacturer Information ................6 Authorized European Representative ............6 Definitions Used in this Manual ..............6 Intended Use ....................6 Operational Life ................... 6 Equipment Identification ................7 Verifying the Package Contents ..............
  • Page 4 Table of Contents User Inspections ....................22 Inspections by an Authorized Service Technician .......... 23 Daily Checklist ....................24 Inspection and Cleaning ................24 Strap Inspection .................... 24 Handling and Storage ................... 24 Battery Replacement ..................25 Verification of the Charger’s Power Source ..........25 Sling Inspection and Care ................

  • Page 5: General Information

    We are dedicated to serving your injuries that can be attributed to the use of inadequate parts, needs and providing the best only parts designated by Arjo should be used on equipment products available along with and other appliances supplied by Arjo.

  • Page 6: Manufacturer Information

    “Preventive Maintenance Schedule.” The equipment must only be used for the purposes The expected life for other consumable products, stated above, and must be installed by Arjo such as batteries, fuses, lamps, slings, straps and authorized personnel and in accordance with local cords is dependent upon the care and usage of the codes.

  • Page 7: Equipment Identification

    Instructions” section, before installing, operating, or servicing this equipment. If anything is not completely understood, please contact your local Arjo representative for more details. Failure to comply with warnings in this manual may result in injuries. Keep this manual with the lift and refer to it as required.

  • Page 8: Symbols Used

    General Information Symbols Used Symbol Key to symbols This symbol is accompanied by the name and the address of the authorized representative in the European Community. This symbol is accompanied by a date to indicate the date of manufacture and by the address of the manufacturer. This symbol indicates the products comply with the medical device directive 93/42/EEC.

  • Page 9: Safety Instructions

    CAUTION: Do not drop the lift, since it may cause internal damage that is not easily seen. If the portable lift is suspected to be damaged, contact your local Arjo representative for servicing. Safe Working Load The Maxi Sky has been designed with a lifting capacity of 200 kg (440 lb).

  • Page 10: Important Safety Directions

    –10ºC and 50ºC (14ºF to 122ºF). Always ensure that: • The portable lift is installed by an authorized NOTE: Arjo portable lifts are specifically Arjo contractor or installer. designed for KWIKtrak ceiling rail systems, • The equipment is used by trained staff.

  • Page 11: Fire And Explosion Prevention

    Safety Instructions Fire and Explosion Prevention Battery and Battery Charger Safety Practices WARNING: Do not place or store the battery under direct sunlight or near a heat WARNING: Do not expose the battery source. Do not expose the batteries or connector or the battery charger to water.

  • Page 12: Part Designation

    Part Designation Maxi Sky Portable Lift and Charger Station Legend 5) Handset holder button DOWN 6) Handset unit 12) Power cord 1) Emergency key 7) Support 13) Charger 2) Pass through hook 8) DC inlet charger 14) Emergency shut-off button 3) Strap button 4) Carabiner...

  • Page 13: Handset

    Part Designation Handset The Maxi Sky ’s handset unit is used to operate the portable lift. Each function is described in Fig. 5. The buttons raise or lower the lift. DOWN button DOWN button Fig. 5...

  • Page 14: Slings

    Slings Compatible Slings Hammock 6 sling Quick Fit sling Hammock sling (THA6-X & THA6I-X) (TIR-X) (THA-X & THAI-X) Hygienic sling Combi sling Walking Sling (THY-X) (62600X-X) (TEM) Limb sling Repositioning sling (624500) (300.20005)

  • Page 15: How To Use The Maxi Sky 440

    Maxi Sky caregiver and enhancing patient safety. The track must be installed and modified only by Arjo authorized personnel and in 6) To attach the sling, unfold the support on each accordance with local codes. side of the lift. Insert the strap loop onto the support and pull gently on the strap.

  • Page 16: Emergency Shut-Off

    The emergency brake is intended for a Emergency Shut-off single activation and therefore can only be used once. Call your Arjo representative The operator can shut off the electrical power at any time pressing...
  • Page 17 How to Use the Maxi Sky Fig. 7...

  • Page 18: Battery Information

    Optionally, the charger can be installed on the wall. If you install it on the wall, the NOTE: Arjo uses sealed lead-acid back of the charger is designed to be clipped on the batteries.

  • Page 19: Use Of Slings

    Terracotta - Extra Extra Large - XXL for long periods of time without charging the batteries. Arjo offer the option of a headrest for many of our slings if it is considered necessary for a particular patient. A range of special purpose slings are available as accessories.

  • Page 20: Pass-Through Hook

    Before Transferring the Lift PARALLEL WITH A 45° ANGLE WARNING: • The track must be installed by Arjo qualified personnel and in accordance with local codes. • All tracks are closed with end stoppers or are connected to other closed track NON-PARALLEL WITH A 45°...

  • Page 21: Pass-Through Procedure

    How to Use the Maxi Sky If any of the diagrams under the “Unacceptable Track Configurations” subheading represent your Down button current installation, attempt the pass- DO NOT through manoeuvre. Failure to comply to these warnings could result in serious injury or damage to the product.

  • Page 22: Care And Maintenance

    WARNING: Safety related maintenance and authorized service must be carried out by qualified personnel, fully trained in servicing procedures by Arjo, and equipped with correct tools. Failure to meet these requirements could result in personal injuries and/or unsafe equipment. User Inspections...

  • Page 23: Inspections By An Authorized Service Technician

    Load test with SWL (maximum working capacity). WARNING: To avoid injuries that can be attributed to the use of inadequate parts, Arjo strongly advises and warns that only Arjo designated parts should be used on equipment and other appliances supplied by Arjo. Unauthorized modifications on any Arjo equipment may affect its safety.

  • Page 24: Daily Checklist

    (see Fig. 17). If there Edge wear (fraying) is any evidence of damage, . Contact DO NOT USE IT your local Arjo representative to have the lift ser- Middle wear viced. • Inspect the sling for tears, frayed straps or loose Fig.

  • Page 25: Battery Replacement

    Source Once that red light begins to flash, please contact If the light does not illuminate when there are your local Arjo representative in order to perform the batteries correctly installed in the Maxi Sky , try necessary maintenance inspection.

  • Page 26: Troubleshooting

    If the load is greater than the unit’s safe working load, it will not func- repetitively. tion due to an overload protection on the motor. • Batteries are low and need to be changed. Contact your local Arjo representative. The lift emits a “beep” during use. •...

  • Page 27: Labels On The Lift

    Labels on the Lift 1) Product name 2) Serial number label 3) Charger information 4) Logo sticker Fig. 18...

  • Page 28: Technical Specifications

    Technical Specifications PRODUCT INFORMATION Maxi Sky Weight, complete 6.35 kg (14 lb) Lifting capacity 200 kg (440 lb) Strap length 2200 mm (88 in) Lifting speed 4.3 cm/s (1.7 in/s) ELECTRICAL Duty cycle Max 10%, 6 min/hr, (max. 1 min. continuous) Rating 24 VDC, 10 A max.

  • Page 29: Lift Dimensions

    Technical Specifications Lift Dimensions 140 mm 180 mm 90 mm 177 mm (7'') 351 mm (13 3/4'') 637 mm (25 1/8'') Fig. 19...
  • Page 32 Fax.420 541 213 550 If your country is not listed here, please contact your local distributor or: ...with people in mind. ARJO International AB, Box 61, S-241 21 Eslov, SWEDEN Tel +46 413 64500. Fax +46 413 555586. www.arjo.com MEMBER OF THE GETINGE GROUP info@arjo.com...
