- Page 1 INSTRUCTIONS FOR USE Strap Extension 001-00629-EN Rev 2 • 2024-03...
- Page 2 © Arjo 2024. As our policy is one of continuous improvement, we reserve the right to modify designs without prior notice. The content of this publication may not be copied either whole or in part without the consent of Arjo.
-
Page 3: Table Of Contents
Safety Directions ............................4 Installation Instructions for the Strap Extension ..............5 Installing the Strap Extension on a Maxi Sky 2 Ceiling Lift and Infection Control models ...... 5 Installing the Strap Extension on a Maxi Sky 2 Basic Ceiling Lift ............6 Care and Maintenance ........................7... -
Page 4: General Information
Intended Use The STRAP EXTENSION is intended to be used exclusively with the Maxi Sky 2 series. The STRAP EXTENSION is part of a series of quality products designed for hospitals, nursing homes and other health care uses. Operational Life... -
Page 5: Symbols Used
UK marking indicating conformity with UK Medical Devices Regulations 2002 (SI 2002 No 618, as amended) UK Responsible Person & UK Importer: Arjo (UK) Ltd, ArjoHuntleigh House, Houghton Regis. LU5 5XF For Northern Ireland (NI) CE marking will still apply until further amendment to applicable regulations. -
Page 6: Safety Instructions
EXTENSION prior to each use in search of If there is anything in the manual that is confusing irregularities as per Care and Maintenance or hard to understand, call Arjo or their vendor (the section on page 7. telephone number appears on the last page of this Failure to follow these instructions may result in manual). -
Page 7: Installation Instructions For The Strap Extension
Installation Instructions for the Strap Extension Installation Instructions for the Strap Extension Installing the Strap Extension on a Maxi Sky 2 Ceiling Lift and Infection Control models 1) Remove the spreader bar from the Maxi Sky 2 (see below). Maxi Sky 2... -
Page 8: Installing The Strap Extension On A Maxi Sky 2 Basic Ceiling Lift
Installing the Strap Extension on a Maxi Sky 2 Basic Ceiling Lift 1) Remove the clevis pin and split ring from the loop end of the Maxi Sky 2 Basic Ceiling Lift strap (Fig. 4). Strap Clevis pin Split ring Fig. -
Page 9: Care And Maintenance
Always read the instructions for use and material rupture can drop rapidly and present a danger for the safety data sheet of the disinfectant. patient or caregiver. Arjo recommends a thorough inspection of the strap every 4 months as follows: •... - Page 10 Disinfection Agents Quaternary Ammonium 0.21% (2,100 ppm) Isopropyl Alcohol Disinfection Agents for Phenolic 1.56% (15,600 ppm) Lift and Accessories Bleach (10,000 ppm) Peracetic Acid 0.25% (2,500 ppm) Hydrogen Peroxide Woven Nylon Extension Strap Coated Extension Strap Care and Maintenance...
-
Page 11: Dimensions
Dimensions Fig. 7 Technical Data PRODUCT INFORMATION STRAP EXTENSION (362-14030) Total weight 0.115 kg (0.25 lb) Lifting capacity 272 kg (600 lb) Material Polyester webbing and PVC coating ENVIRONMENTAL CONDITIONS Ambient temperature range Operation and Storage: -40°C to 70°C (-40°F to 158° F) - Page 12 Intentionally left blank...
- Page 13 Intentionally left blank...
- Page 14 Intentionally left blank...
- Page 15 AUSTRALIA FRANCE Arjo Australia Arjo SAS Arjo Polska Sp. z o.o. Building B, Level 3 2 Avenue Alcide de Gasperi 11 Talavera Road CS 70133 Macquarie Park, NSW, 2113, FR-59436 RONCQ CEDEX Tel: +48 691 119 999 Australia Tél: +33 (0) 3 20 28 13 13 E-mail: arjo@arjo.com...
- Page 16 At Arjo, we believe that empowering movement within healthcare environments is essential to quality care. Our products and solutions are prevention of pressure injuries and venous thromboembolism. With over 6500 people worldwide and 65 years caring for patients and healthcare professionals, we are committed to driving healthier outcomes for people facing mobility challenges.
