LED LED State
RBOK On Green
Off
FAOK On Green
Blinking
Green
Off
PWR On Green
Blinking
Green
On Red
Off
Front Ethernet Indicators (LAN1, LAN2, LAN3 RJ45 Built-in LEDs)
LED LED State
Link On Green The corresponding link has been established.
Status
Blinking
(upper)
Green
Off
Link On Green Corresponding data speed is 1 Gbps or 100 Mbps.
Speed
Off
(lower)
Bottom Ethernet Indicators (EFA RJ45 Built-in LED)
LED LED State
Link On Green
Status
Blinking
(upper)
Green
Off
Link On Green
Speed
On Yellow EFA port only: network data speed is 100 Mbps
(lower)
Off
GFK-3002A
Operating State
Remote Redundant CPU is Ready.
Remote Redundant CPU is not Ready.
Field Agent Running and Connected to Cloud.
Blink at 0.5 Hz: Field Agent Starting.
Blink at 1 Hz: Field Agent Running.
Field Agent Off.
CPU running.
Booting up – diagnostics in progress.
Off
Reset / Power not detected.
Operating State
Traffic is detected at the corresponding port.
No connection established at corresponding port.
Corresponding network data speed is 10 Mbps
Operating State
The corresponding link has been established.
Traffic is detected at the corresponding port.
No connection established at corresponding port.
Corresponding network data speed is 1 Gbps.
Corresponding network data speed is 10 Mbps
