- Page 2 CSP105 ‘75 VINTAGE PHASE 45 DIRECTIONS SPECIFICATIONS DESCRIPTION • Run a cable from your guitar to the Input Impedance 500 kΩ • Hand-wired circuit board built with Vintage Phase 45’s Input jack and run original-spec 1975 components Output Impedance 5 kΩ another cable from the Vintage Phase • Original high-quality Switchcraft Max Input Level -5 dBV 45’s Output jack to your amplifier. Input/Output jacks and Carling Signal to Noise Ratio* > 96 dB • Set the Vintage Phase 45’s Speed bypass switch Phase Shift Range 360° control knob to the 12 o’clock position. • Hand-selected FETs, matched to Bypass Hardwire • Turn the effect on by depressing produce deep and rich phasing Current Draw < 1 mA the footswitch.
