What are ZS sensors?
Rnet wiring specifications
The Rnet communicates at a rate of 115 kbps and should be wired in a daisy-chain, star, or hybrid configuration.
NOTE Use the specified type of wire and cable for maximum signal integrity.
Description
Conductor
Maximum length
Insulation
Color Code
Shielding
UL temperature rating
Voltage
Listing
AURORA UPC ZS ZONE SENSORS INSTALLATION GUIDE
4 conductor, shielded or unshielded, CMP, plenum rated cable
22 AWG (7x0096) bare copper
500 feet (152 meters)
Low-smoke PVC (or equivalent)
Black, white, green, red
If shielded, Aluminum/Mylar shield (100% coverage) with TC drain wire
32–167°F (0–75°C)
300 Vac, power limited
UL: NEC CL2P, or better
7
