Kusam-meco KM 2777 Operation Manual

An ISO 9001:2008 Company
SPECIAL FEATURES :
TM
AutoCheck Voltage & Ohms
VFD-V & VFD-Hz function
5ms CREST-MAX capture mode (Peak Hold)
Autoranging Relative -Zero mode
Display Hold function
GENERAL SPECIFICATIONS :
Sensing : TRMS sensing
Jaw Opening : 55mm max.
Display : 3-5/6 digits 6000 counts &
3½ digits 1,999 counts for Hz.
Update Rate : 5 per second nominal
Polarity : Automatic
Low Battery : Below approx 2.4V
Operating Temperature : 0 C to 40 C
Relative Humidity : Maximum 80% R. H.
o
for temperature upto 31 C decreasing linearly
to 50% Relative Humidity at 40 C
Storage Temperature : -20 C to 60 C,
< 80% R.H. (With battery removed)
SAFETY :
Double insulation per IEC/EN61010-1 2 Ed.,
nd
UL61010-1 2 Ed., & CAN/CSA C22.2
No.61010.1-0.92 to Category
CAT IV 1000V AC & DC.
Transient Protection : 12 kV (1.2/50 s surge)
Overload Protection :
Clamp-on jaws : 2000A rms continuous
" + " & COM Terminals (all other functions) :
1000V rms.
Accuracy is ± (% readings digits + number of digits) or otherwise specified, at 23 C ± 5 C & less than 75% R.H.
True RMS Model KM 2777 voltage accuracies are specified from 5% to 100% of range or otherwise specified.
ACA CURRENT(Clamp on)
Range
Resolution
50Hz – 60Hz
200.0 A 100 mA
0 ~ 500 A 1 A
500~2000 A 1 A
40Hz~50Hz & 60Hz~400Hz
200.0 A 100 mA
0 ~ 500 A 1 A
500~1000 A 1 A
1000~2000 A 1 A
True RMS Crest Factor :
< 1.4:1 at full scale & <2.8:1 at half scale
1)
Induced error from adjacent current carrying conductor :
<0.1A/A
D:\Chhaya\My Documents\Chhaya\backup\catlog\New cat\KM 2776-KM 2777.cdr
®
AC / DC TRMS Clamp-On Multimeter with
EF-Detection (NCV)
Backlight LCD Display
Auto Power Off
Diode Test & Continuity Test
PC Interface (Optional)
Altitude : Operating below 2000m
Temperature Coefficient : nominal 0.15 x (specified accuracy) / °C @
Power supply : Standard 1.5V AAA Battery x 2.
Power Consumption : Typical 14mA for Current function,
APO Timing : Idle for 34 minutes
o o
APO Consumption : 10 A typical
Dimension : 264(L) x 97(W) x 43(H) mm
Weight : Approx. 608gm.
o
Accessories : Test leads (pair), user's manual, Bkp60 banana plug
o o
Optional Accessories : USB interface kit BRUA-19X,
nd Pollution degree : 2
EMC : Meets EN61326-1:2006 (EN55022,EN61000-3-2,EN61000-3-3,
EN61000-4-2, EN61000-4-3, EN61000-4-4,EN61000-4-5,EN61000-4-6,
EN61000-4-8,EN61000-4-11)
In an RF field of 3V/m :
Performance above 3V/m is not specified.
ELECTRICAL SPECIFICATIONS : KM 2777
Maximum Crest Factor <1.4:1 at full scale & <2.8:1 at half scale, & with frequency components
within the specified frequency bandwidth for non-sinusoidal waveforms.
DCA CURRENT(Clamp on)
1)
Range
Accuracy
200.0
±(2.0%rdg + 5dgts)
0 ~ 500
±(2.5%rdg + 5dgts)
500~2000 A
±(3.0%rdg + 5dgts) 1 )
Induced error from adjacent current carrying conductor :
<0.1A/A
2 )
Specified with Relative Zero
±(2.5%rdg + 5dgts)
non-zero residual readings, if any.
±(3.0%rdg + 5dgts)
±(3.5%rdg + 5dgts)
Unspecified
VFD, EF-Detection & PC Interface
Model KM 2777 - TRUE RMS SENSING
o o o o
(0 C--18 C or 28 C--40 C), or otherwise specified
& 5.2mA for others.
K-type Thermocouple x 1 & carrying case.
plug to type-K socket plug adaptor
Capacitance function is not specified
Other function ranges : Total Accuracy = Specified Accuracy + 200 digits
Resolution Accuracy
±(2.0%rdg + 5dgts)
A 100 mA
±(2.0%rdg + 5dgts)
A 1 A
±(2.5%rdg + 5dgts)
1 A
mode applied to offset the
BKB32 banana
Preliminary Data
o o
DC + ACA CURRENT(Clamp on)
1)2)
Range
Resolution
DC, 50Hz ~ 60Hz
200.0 A 100 mA
2000 A 1
40Hz ~ 50Hz & 60Hz ~ 400Hz
200.0 A 100 mA
0 ~ 1000 A 1
1000~2000 A 1
True RMS Crest Factor :
< 1.4:1 at full scale & <2.8:1 at half scale
1)
Induced error from adjacent current carrying conductor :
<0.1A/A
2 )
Specified with Relative Zero
non-zero residual readings, if any.
Note: All Specification are Subject to change without prior notice.
1)2)
Accuracy
±(3.0%rdg + 8dgts)
A
±(3.5%rdg + 8dgts)
A
Unspecified
A
mode applied to offset the
Contd....2
