Icom IC-7851 Instruction Manual page 2

■ Addtional CI-V commands
The following commands are added to the conven-
tional Command table.
Cmd. Sub Cmd. Data
1A* 05 0320 see below
0321 00/01
29* 00/01 +
Supported
commends
see below
* Send/read data
• SSB-D transmission passband width settings
Command: 1A 050320
X X
Lower edge: 0=100 Hz
Higher edge: 0=2500 Hz
• Setting after directly specify the Main/Sub band
Command : 29
Specify the Main or Sub band before entering the sup-
ported commands.
When you receive the OK code (FB), or the NG code
(FA), the Command 29 and Main/Sub specify (00/01)
is omitted.
Supported commands
2 9 X X X X X X
00: MAIN
01: SUB Commands
The supported commands are listed to the right col-
umn.
V1.30
Description
Send/read the transmission pass-
band width for the SSB-D mode.
Send/read the timer setting of the
USB SEND/Keying Inhibit at Con-
nection.
00=OFF, 01=ON
Regardless of active/inactive the
Main or Sub band, you can directly
specify the Main or Sub band, and
send/read the supported command
settings.
00=MAIN, 01=SUB
1=200 Hz
2=300 Hz
3=500 Hz
1=2700 Hz
2=2800 Hz
3=2900 Hz
... X X
Data
• Supported command table
Sub
Cmd. Data
Cmd.
07
11* 00
03
06
09
12
15
18
21
12* 00 00 or 01 Select/read ANT1 selection
01 00 or 01 Select/read ANT2 selection
02 00 or 01 Select/read ANT3 selection
03 00
14* 01 0000 to
0255
02 0000 to
0255
03 0000 to
0255
05 0000 to
0255
06 0000 to
0255
07 0000 to
0255
08 0000 to
0255
0D 0000 to
0255
11 0000 to
0255
12 0000 to
0255
13 0000 to
0255
15 01 00
01
02 0000 to
0255
05 00
01
* Send/read data
2
Description
Select VFO mode
Send/read attenuator OFF
Send/read 3 dB attenuator
Send/read 6 dB attenuator
Send/read 9 dB attenuator
Send/read 12 dB attenuator
Send/read 15 dB attenuator
Send/read 18 dB attenuator
Send/read 21 dB attenuator
(00=RX ANT OFF; 01=RX ANT ON)
(00=RX ANT OFF; 01=RX ANT ON)
(00=RX ANT OFF; 01=RX ANT ON)
Select/read ANT4 selection
(00=RX ANT OFF; fix)
Send/read [AF] level
(0000=max. CCW, 0255=max. CW)
Send/read [RF] level
(0000=max. CCW, 0255=max. CW)
Send/read [SQL] level
(0000=max. CCW, 0255=max. CW)
Send/read [APF] position
(0000=Pitch–550 Hz, 0128=Pitch,
0255=Pitch+550 Hz; 10 Hz steps)
Send/read [NR] level
(0000=0%, 0255=100%)
Send/read inner [TWIN PBT] position
( 0000=max. CCW, 0128=center,
0255=max. CW)
Send/read outer [TWIN PBT] position
( 0000=max. CCW, 0128=center,
0255=max. CW)
Send/read [NOTCH] position
( 0000=max. CCW, 0128=center,
0255=max. CW)
Send/read [AGC] level
(0000=max. CCW to 0255=max. CW)
Send/read NB level
(0000=0%, 0255=100%)
Send/read [DIGI-SEL] position
(0000=max. CCW to 0255=max. CW)
Read noise or S-meter squelch status
(squelch close)
Read noise or S-meter squelch status
(squelch open)
Read S-meter level
(0000=S0, 0120=S9, 0241=S9+60 dB)
Read various squelch (tone squelch,
and so on) status (squelch close)
Read various squelch (tone squelch,
and so on) status (squelch open)
 Continue on the next page
A7205-6EX
