MOTION DETECTOR WITH
CONSTANT LIGHT CONTROL
DM KNT 003
INSTRUCTIONS MANUAL
DINUY S.A. c/Auzolan 2, 20303 Irun (SPAIN)
Tel.: +34 943627988 – E-mail:
knx@dinuy.com
– Web:
www.dinuy.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KNX DM KNT 003 and is the answer not in the manual?

Questions and answers

Summary of Contents for DINUY KNX DM KNT 003

  • Page 1 MOTION DETECTOR WITH CONSTANT LIGHT CONTROL DM KNT 003 INSTRUCTIONS MANUAL DINUY S.A. c/Auzolan 2, 20303 Irun (SPAIN) Tel.: +34 943627988 – E-mail: knx@dinuy.com – Web: www.dinuy.com...
  • Page 2: General Description

    Universal mechanism box mounted Ambient temperature -10ºC ~ +45ºC Type of protection IP20 (EN60529) Safety class According to the Standard EN50090-2-2, EN50428 & EN50491 Certification EIB/KNX DINUY S.A. c/Auzolan 2, 20303 Irun (SPAIN) Tel.: +34 943627988 – E-mail: knx@dinuy.com – Web: www.dinuy.com...
  • Page 3 Enabled Object: Brightness sensor This function allows measuring the level of light in the sensor and sending this value to the bus. Enabled Object: DINUY S.A. c/Auzolan 2, 20303 Irun (SPAIN) Tel.: +34 943627988 – E-mail: knx@dinuy.com – Web: www.dinuy.com...
  • Page 4 Lag time: Time base of lag time x Time factor of lag time • Standard: either the “Lux Threshold” as the “Lag Time” is set by default values: 5lux and 3min. DINUY S.A. c/Auzolan 2, 20303 Irun (SPAIN) Tel.: +34 943627988 – E-mail: knx@dinuy.com...
  • Page 5 Allows making the sensor more or less sensitive to movements. A high sensitivity (1) makes it detects the slightest movement, while a low sensitivity (255) prevents unwanted false detections. DINUY S.A. c/Auzolan 2, 20303 Irun (SPAIN) Tel.: +34 943627988 – E-mail: knx@dinuy.com...
  • Page 6: Monitoring Function

    OFF Telegram o Cyclic ON Telegram: ON is sent periodically. The time between two sending: ‘Time Base for cyclic transmission’ x ‘Time Factor for cyclic transmission’. DINUY S.A. c/Auzolan 2, 20303 Irun (SPAIN) Tel.: +34 943627988 – E-mail: knx@dinuy.com –...
  • Page 7: Twilight Sensor

    ON Telegram o OFF Telegram o Cyclic ON Telegram: ON is sent periodically. The time between two sending: ‘Time Base for cyclic DINUY S.A. c/Auzolan 2, 20303 Irun (SPAIN) transmission’ x ‘Time Factor for cyclic transmission’. Tel.: +34 943627988 – E-mail: knx@dinuy.com...
  • Page 8: Constant Light Control

    Possible to select the trigger telegram ('Enable function with'): • ON Telegram • OFF Telegram Enabled Object: Behaviour on bus voltage recovery – comm. object constant light control enable DINUY S.A. c/Auzolan 2, 20303 Irun (SPAIN) Tel.: +34 943627988 – E-mail: knx@dinuy.com – Web: www.dinuy.com...
  • Page 9 Constant light object number Allows to control several lighting lines (up to 4) with an adjustable percentage of increase: ‘2nd constant light object attenuation’. Enabled Object: DINUY S.A. c/Auzolan 2, 20303 Irun (SPAIN) Tel.: +34 943627988 – E-mail: knx@dinuy.com – Web:...
  • Page 10: Temperature Sensor

    This function simply allows getting the Lux value measured by the sensor. This value will be sent from time to time established by: ‘Time base for cyclic transmission’ x ‘Time factor for cyclic transmission’. DINUY S.A. c/Auzolan 2, 20303 Irun (SPAIN) Tel.: +34 943627988 – E-mail: knx@dinuy.com –...
