PRESSURA
™
ROOM PRESSURE CONTROLLER
MODEL RPC30
OPERATION AND SERVICE MANUAL
P/N 6006643, REVISION G
JULY 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRESSURA RPC30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TSI Instruments PRESSURA RPC30

Summary of Contents for TSI Instruments PRESSURA RPC30

  • Page 1 PRESSURA ™ ROOM PRESSURE CONTROLLER MODEL RPC30 OPERATION AND SERVICE MANUAL P/N 6006643, REVISION G JULY 2018...
  • Page 3 PRESSURA ™ ROOM PRESSURE CONTROLLER MODEL RPC30 OPERATION AND SERVICE MANUAL P/N 6006643, REVISION G JULY 2018 U.S. AND CANADA OTHER COUNTRIES Sales & Customer Service: Sales & Customer Service: (800) 680-1220 / (651) 490-2860 (001 651) 490-2860 Fax: Fax: (651) 490-3824 (001 651) 490-3824 SHIP/MAIL TO:...
  • Page 5 Copyright  TSI Incorporated / 2013-2018 / All rights reserved. Part number 6006643 / Rev G / July 2018 Limitation of Warranty and Liability (effective April 2014) (For country-specific terms and conditions outside of the USA, please visit www.tsi.com.) Seller warrants the goods, excluding software, sold hereunder, under normal use and service as described in the operator's manual, to be free from defects in workmanship and material for 24 months, or if less, the length of time specified in the operator's manual, from the date of shipment to the customer.
  • Page 6 Service Policy Knowing that inoperative or defective instruments are as detrimental to TSI as they are to our customers, our service policy is designed to give prompt attention to any problems. If any malfunction is discovered, please contact your nearest sales office or representative, or call TSI's Customer Service department at (800) 680-1220 or (651) 490-2860.

  • Page 7: Table Of Contents

    CONTENTS HOW TO USE THIS MANUAL ....................... 1 Safety Information ....................1 Description of Caution Symbol ................1 Access Code / Passcode .................. 1 PART ONE ............................. 3 User Basics ......................3 The Instrument ..................... 3 Useful User Information..................3 Operator Panel .....................

  • Page 8: Table Of Contents

    APPENDIX A ..........................87 Specifications* ....................87 APPENDIX B ..........................89 Network Communications ................... 89 ® Modbus Communications ................. 89 Unique to TSI ....................89 Network Points RAM Variables ............... 90 XRAM Variables ....................91 RPC30 Variable List ..................91 ®...

  • Page 9: Safety Information

    How to Use This Manual The Operation and Service Manual describes how to operate, configure, calibrate, maintain and troubleshoot the Model RPC30 Room Pressure Controller. The manual is divided into two parts. Part one describes the unit and how to interface with the device. This section should be read by users, facilities staff, and anyone who requires a basic understanding of how the device operates.
  • Page 10 (This page intentionally left blank)

  • Page 11: User Basics

    Part One User Basics This section is designed to provide a brief but thorough overview of the product installed. These few pages explain the purpose (The Instrument) and the operation (Useful user information, Operator panel, Alarms) of the product. Technical product information is available in Part Two of the manual.

  • Page 12: Display Screen

    Figure 2. Two Room Screen Display Screen The LCD display is highly configurable and can display various critical information including pressure differential, flow rate, alarm status, menu options, and error messages. In addition, the LCD display is used for programming the unit. When programming the unit, the display will show menus, menu items, and current value of the menu item, depending on the specific programming function being performed.

  • Page 13: Usb Port

    USB Port There is a USB port on the case. This USB port can be used with TSI’s Configuration Software. Figure 3. USB Port Location Alarms The Model RPC30 controller has visual (red light) and audible alarms to inform you of changing room conditions.

  • Page 14: Alarm Relays

    Alarm Relays The PresSura controllers feature 2 alarm relays. The alarm relays can be field configured to either open or close to indicate an alarm condition, although they will close on loss of power. Relay 1 functions as the low alarm relay, and will activate after the alarm delay for low pressure, low flow, low temperature and low RH alarms.

  • Page 15: Technical Section

    Part Two Technical Section The PresSura™ Room Pressure Controller is ready to use after being properly installed and configured. The TSI through-the-wall sensor is factory calibrated, as are most pressure transducers. Figure 4 shows the Digital Interface Module (DIM) which is programmed with a default configuration that can be easily modified to fit your application.

  • Page 16: Software Programming

    Software Programming Programming the PresSura Model RPC30 controller is quick and easy if the proper keystroke procedure is followed. The programming keys are defined first, followed by the required keystroke procedure. At the end of this section is a programming example. NOTE: It is important to note that the unit is always operating when programming.

  • Page 17: Entering Menus

    Entering Menus Swipe across the display, from the top right corner to the bottom left corner, to access the menu system. Figure 7. Swipe to access menu system Menus and Menu Items After accessing a menu, the screen will change to show the items associated with that menu. Refer to the Menu and Menu Items section for a list of the menus and their associated items.
  • Page 18 Drop-Down Selection It is easy to view available choices and make a selection from drop-down items. Touch the item displayed in the drop-down box to view all available options. Then, touch the item desired. Touch the Save button to save your selection and exit the item or touch the Cancel button to exit the item without saving.

  • Page 19: Programming Example

    Programming Example The following example demonstrates the keystroke sequence. In this example the negative low alarm set point for Room 1 will be changed from -0.01000 in. W.C. to -0.01300 in. W.C.  Unit is in normal operation.  Swipe from the top right to the bottom left corner to access the menu system.

  • Page 20: Menu And Menu Items

     Enter the new setpoint of - 0.01300 in. W.C. Save the new setting.  Touch the Exit button in the Rm1 Alarm menu and again in the main menu to return to the main running screen. Menu and Menu Items The PresSura Model RPC30 controllers are very versatile devices which can be configured to meet your specific application.
  • Page 21 Rm1 Setpnts Alarm Config Control Diagnostics Neg Setpnt Alarm Reset Speed_P View Inputs Pos Setpnt Audible Alm Sensitivity_P View Outputs No Iso Type Alarm Delay Speed_F Relay Outputs No Iso Setpnt Mute Time Sensitivity_F Flow Control Temp Heat Door Delay Exh Cntl Dir Temp Control Temp Cool...

  • Page 22: Configure Menu

    Configure Menu MENU ITEM SOFTWARE Monitor/ ITEM DESCRIPTION ITEM RANGE DEFAULT VALUE NAME Controller Number of Rooms # of Rooms The # of Rooms item selects the number of rooms the 1 Room 1 Room Monitored Model RPC30 controller will monitor and control. 1 Room with Anteroom The Press Modes item determines the room modes...
  • Page 23 Configure Menu MENU ITEM SOFTWARE Monitor/ ITEM DESCRIPTION ITEM RANGE DEFAULT VALUE NAME Controller EXHAUST/SUPPLY/ Devices Controlled Ctrl Devices The Ctrl Devices item selects what will be controlled in EXHAUST TEMP, EXHAUST, the primary room. SUPPLY, NONE EXHAUST / Configures the Model RPC30 to control SUPPLY / room exhaust, supply and heat to TEMP...
  • Page 24 Configure Menu MENU ITEM SOFTWARE Monitor/ ITEM DESCRIPTION ITEM RANGE DEFAULT VALUE NAME Controller Devices Controlled NOTE: Ctrl Devices can only be set to (continued) EXHAUST/SUPPLY/TEMP if the # of Rooms item is set to 1. If Ctrl Devices is set to EXHAUST/SUPPLY/TEMP, the RPC30 will make the following settings in the Interface menu: ...
  • Page 25 Configure Menu MENU ITEM SOFTWARE Monitor/ ITEM DESCRIPTION ITEM RANGE DEFAULT VALUE NAME Controller Measurements Display Meas The Display Meas item selects which measurements will Room Status, Room Room Status Displayed be presented on the display during normal operating Pressure, All mode.
  • Page 26 Configure Menu MENU ITEM SOFTWARE Monitor/ ITEM DESCRIPTION ITEM RANGE DEFAULT VALUE NAME Controller Configure INPUT2 Input 2 The Input 2 item selects the desired input type for Input2, TSI Sensor, None the room pressure sensor for the AnteRm. Pressure Transducer, Temperature Setpoint Go to the Input2 menu to adjust parameters such as None...
  • Page 27 Configure Menu MENU ITEM SOFTWARE Monitor/ ITEM DESCRIPTION ITEM RANGE DEFAULT VALUE NAME Controller Configure INPUT7 Input 7 The Input 7 item selects the desired input type for Input7. Room1 Supply Air None Temperature, Go to the Input 7 menu to adjust parameters such as Exhaust Pressure sensor range associated with Input7.
  • Page 28 Configure Menu MENU ITEM SOFTWARE Monitor/ ITEM DESCRIPTION ITEM RANGE DEFAULT VALUE NAME Controller Enable Access Passcode The Passcode item selects whether an access code Menus Codes (pass code) is required to enter the menu items. The Room Mode Passcode item prevents unauthorized access to a menu. Menus If the Passcode item is: Set Room Mode...
  • Page 29 Room1 Alarm Menu SOFTWARE MENU ITEM ITEM DESCRIPTION ITEM RANGE DEFAULT VALUE NAME Mode of Room 1 Room Mode The Room Mode item selects the room pressure Positive Negative direction. This item enables all related alarms, for Negative pressure direction selected. The PresSura Model RPC30 Controller will use the following control parameters: Room...
  • Page 30 Room1 Alarm Menu SOFTWARE MENU ITEM ITEM DESCRIPTION ITEM RANGE DEFAULT VALUE NAME Room 1 Negative Neg Low Alm The Neg Low Alm item sets the negative low pressure -0.19500 in. W.C. to -0.01.0 in. W.C. Low Alarm alarm setpoint. A low alarm condition is defined as when +0.19500 in.
  • Page 31 Room1 Alarm Menu SOFTWARE MENU ITEM ITEM DESCRIPTION ITEM RANGE DEFAULT VALUE NAME Room 1 Positive Pos Low Alm The Pos Low Alm item sets the positive low pressure -0.19500 in. W.C. to +0.01.0 in. W.C. Low Alarm alarm setpoint. A low alarm condition is defined as when +0.19500 in.
  • Page 32 Room1 Alarm Menu SOFTWARE MENU ITEM ITEM DESCRIPTION ITEM RANGE DEFAULT VALUE NAME Room 1 Low Sup Low Alm The Sup Low Alm item sets the minimum supply flow 0 to 30,000 cfm 0 cfm Supply Flow Alarm alarm setpoint. A minimum flow alarm is defined as when NOTE the supply flow is less than the Sup Low Alm setpoint.
  • Page 33 Room1 Alarm Menu SOFTWARE MENU ITEM ITEM DESCRIPTION ITEM RANGE DEFAULT VALUE NAME Duct for Air ACH Duct The ACH Duct item sets the duct to be used for ACH Changes per Hour calculations: SUPPLY Calculation EXHAUST SUPPLY is normally used for positive rooms EXHAUST is normally used for negative rooms is used if the ACH calculation is not desired...
  • Page 34 AnteRm Alarm Menu SOFTWARE MENU ITEM ITEM DESCRIPTION ITEM RANGE DEFAULT VALUE NAME Anteroom Negative Neg Hi Alm The Neg Hi Alm item sets the negative high pressure -0.19500 in. W.C. to -0.1.0 in. W.C. High Alarm alarm setpoint. A high alarm condition is defined as when +0.19500 in.

  • Page 35: Alarm Constraints

    AnteRm Alarm Menu SOFTWARE MENU ITEM ITEM DESCRIPTION ITEM RANGE DEFAULT VALUE NAME Anteroom Positive Pos Hi Alm The Pos Hi Alm item sets the positive high pressure -0.19500 in. W.C. to +0.1.0 in. W.C. High Alarm alarm setpoint. A high alarm condition is defined as when +0.19500 in.
  • Page 36 3. Alarms do not terminate until the room pressure slightly exceeds the alarm setpoint. 4. The ALARM RESET item selects how the alarms will terminate when the controller returns to the safe range. The pressure and flow alarms all terminate the same; they are either latched or unlatched. If unlatched is selected the alarms automatically turn off when the value slightly exceeds the alarm setpoint.

  • Page 37: Rm1 Setpnts Menu

    Rm1 Setpnts Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE 0 to Room 1 Negative Neg Setpnt The Neg Setpnt item sets the negative pressure control -0.02 in. W.C. -0.19500 in. W.C. Pressure Setpoint setpoint. The PresSura controller will maintain the room under negative pressure when item is enabled.
  • Page 38 Rm1 Setpnts Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Room 1 No No Iso Type The No Iso Type item sets the method of control when Flow Position Isolation Mode the PresSura controller is in NO ISOLATION mode. Position Control Pressure...
  • Page 39 Rm1 Setpnts Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Room 1 Minimum Unoc Heat The Unoc Heat item is the temperature at which the 55 to 85°F 65°F Temperature for heating valve is expected to be fully open. The throttling Heating –...
  • Page 40 Rm1 Setpnts Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Room1 Heating Heat Flow The Heat Flow item sets the maximum supply flow for 0 to 10,000 CFM 0 CFM Supply Flow Rate heating. NOTE NOTE: Input7 must be configured to ROOM1 SUPPLY Heat Flow cannot AIR TEMP SENSOR for this item to be active.
  • Page 41 Rm1 Setpnts Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Room1 Unoccupied Unoc Min The Unoc Min Flow item sets the minimum supply flow 0 to 10,000 CFM 0 CFM Mode Minimum Flow for unoccupied mode. NOTE Supply Flow NOTE: Input3 must be configured to measure supply flow Unoc Min Flow...
  • Page 42 Rm1 Setpnts Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Room1 Maximum Max Exh Flow The Max Exh Flow item sets the maximum exhaust flow 0 to 10,000 CFM 0 CFM Exhaust Flow rate for Room1. NOTE NOTE: Input7 must be configured for an exhaust flow Max Exh Flow measurement for this item to be active.

  • Page 43: Alarm Config Menu

    Alarm Config Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Alarm Reset Alarm Reset The Alarm Reset item selects how the alarms terminate Latched Unlatched after the unit returns to control set point. The Alarm Reset Unlatched affects the audible alarm, visual alarm, and relay output, which means all are latched or unlatched.
  • Page 44 Alarm Config Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE 1 to 600 seconds 60 seconds Door Delay Door Delay The Door Delay item sets the period of time the room pressure differential, flow or temperature must be above the high alarm set point or below the low alarm set point before the controller enters alarm mode when the door is open.

  • Page 45: Control Menu

    Control Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE The Speed_P item selects the control output speed. The 10% to 100% Pressure Control Speed_P greater the Speed_P setting, the faster the control output. Speed 10% to 100% Pressure Control Sensitivity-P The Sensitivity_P item selects the integral dead band.
  • Page 46 Control Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE The Sup Cntl Dir item determines the control signal’s Supply Control Sup Cntl Dir Direct Direct Direction output direction. As an example: if the control system Reverse closes the supply damper instead of opening the damper, this option will reverse the control signal to now open the damper.
  • Page 47 Control Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Pressure and Flow Sup Kc The Sup Kc and Exh Kc items change the gain control Sup Kc = 0 to Sup Kc = 75 Control Coefficients Exh Kc coefficient.

  • Page 48: Interface Menu

    Interface Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE ® Network Comm Type The Comm Type item selects the communications protocol Modbus Modbus ® Communications used to interface with the building management system. BACnet Protocol NOTE: LON can only be selected on the Model RPC30-LON.
  • Page 49 Interface Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Network Address Nurse The Nurse Address item sets the main network address of 1 to 8 for Nurse’s Station Address the room pressure controller when communicating with the Nurse’s Station Monitor.
  • Page 50 Interface Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Analog Output AO1 Sig The AO1 Sig Type item selects the measurement that the Exhaust Control, Exhaust Signal Type Type analog output signal will represent. None Control NOTE: Changing the AO1 Sig Type item when Ctrl Device is set to EXHAUST or EXHAUST/SUPPLY/TEMP may result in loss of room or temperature control.
  • Page 51 Interface Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Analog Output Full AO2 Sig The AO2 Sig Rnge item selects the full scale range that PRESSURE: PRESSURE: Scale Rnge the analog output signal will represent. If the room pressure -1.00 in.
  • Page 52 Interface Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Analog Output AO3 Out The AO3 Out Type item selects the analog output (not 0 to 10 VDC or 0 to 10 VDC Signal Type control output signal). 4-20 mA NOTE: Changing the AO3 Out Type item when Ctrl Device is set to EXHAUST/SUPPLY/TEMP...

  • Page 53: Diagnostics Menu

    Diagnostics Menu SOFTWARE MENU ITEM ITEM DESCRIPTION NAME View Measurement View Inputs The View Inputs item allows the user to view the measurements for all 7 inputs on one screen. Inputs View Output View Outputs The View Outputs item allows the user to view the current output signals, in units of V or mA. Signals NOTE: Use the Flow Control or Temp Control items to manually control the output signals.
  • Page 54 Input1 Config Menu TSI Sensor SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Set Sensor Zero Sensor Zero The Sensor Zero item is used to re-zero the TSI Sensor None Unit is factory Calibration zero calibration point. calibrated and should not need adjustment.
  • Page 55 Input1 Config Menu TSI Sensor SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Check Sensor Check Status The Check Status item is used to check the None Status communication status of the sensor. After pressing the button, the PresSura unit will respond with: COMM ERROR DIM cannot communicate with sensor.
  • Page 56 Input1 Config Menu Press Trans SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Set Minimum Sensor Min The Sensor Min item is used to set the minimum reading -1.00 to Sensor Pressure of a pressure transducer used to measure room pressure +1.00 in.
  • Page 57 Input2 Config Menu TSI Sensor SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Set Sensor Zero Sensor Zero The Sensor Zero item is used to re-zero the TSI Sensor None Unit is factory Calibration zero calibration point. calibrated and should not need adjustment.
  • Page 58 Input2 Config Menu TSI Sensor SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Check Sensor Check Status The Check Status item is used to check the None Status communication status of the sensor. After pressing the button, the PresSura unit will respond with: COMM ERROR DIM cannot communicate with sensor.
  • Page 59 Input2 Config Menu Press Trans SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Set Minimum Sensor Min The Sensor Min item is used to set the minimum reading -1.00 to Sensor Pressure of a pressure transducer used to measure room pressure +1.00 in.
  • Page 60 Input2 Config Menu Temp Setpnt SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Set Minimum Sensor Min The Sensor Min item is used to set the minimum reading -10°F to 0°F -5°F Temperature of the thermostat. For example, if the temperature Adjustment adjustment of the thermostat is from -5°...
  • Page 61 Input3 Config Menu Sup Pres Flow SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Set Flow Station Duct Area The Duct Area item is used to program the cross sectional 0 to 50.00 ft 0.00 ft Duct Area area of the duct where the flow station is mounted.
  • Page 62 Input3 Config Menu Sup Pres Flow SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Set Flow Station Sensor Zero The Sensor Zero item is used to re-zero the pressure NONE Zero Calibration transducer zero calibration point. Set Maximum Sensor Max The Sensor Max item is used to set the maximum reading -1.00 to + 1.00...
  • Page 63 Input3 Config Menu Sup Lin Flow SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Set Flow Station Duct Area The Duct Area item is used to program the cross sectional 0 to 50.00 ft 0.00 ft Duct Area area of the duct where the flow station is mounted.
  • Page 64 Input3 Config Menu Sup Lin Flow SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Set Maximum Sensor Max The Sensor Max item is used to set the maximum reading 0 to 10,000 ft/min Sensor Output of a flow station used to measure supply air flow. The Sensor Max item has increments of 1000 ft/min.
  • Page 65 Input3 Config Menu Sup Venturi SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Minimum Flow Min Flow The Min Flow item sets the flow rate through the venturi 0 to 10000 cfm 0 cfm valve when it is fully closed. The display will indicate a volumetric flow rate.
  • Page 66 Input3 Config Menu Sup Venturi SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Reset Calibration Reset Cal The Reset Cal item is used to return to the factory default None calibration, undoing any field calibration adjustments. When this menu item is entered, the controller will prompt the user to verify that they want to do this by displaying the message “Are You Sure.”...
  • Page 67 Input4 Config Menu Rm1 Occ Sen SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Room Unoccupied Unocc Sig The Unocc Sig item is used to set the signal that indicates Open, Closed Closed Signal the room is unoccupied. Input5 Config Menu Rm1 Key Switch ITEM DESCRIPTION...
  • Page 68 Input5 Config Menu SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Reset Calibration Reset Cal The Reset Cal item is used to return to the factory default None calibration, undoing any field calibration adjustments. When this menu item is entered, the controller will prompt the user to verify that they want to do this by displaying the message “Are You Sure.”...
  • Page 69 Input6 Config Menu Ante Dr Sw SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Signal to Indicate The Dr Open Sig item sets the signal the Model RPC30 Dr Open Sig Open, Closed Closed Open Door Room Pressure Controller will receive to indicate a door is open.
  • Page 70 Input7 Config Menu Exh Pres Flow SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Set Flow Station Duct Area The Duct Area item is used to program the cross sectional 0 to 50.00 ft 0.00 ft Duct Area area of the duct where the flow station is mounted.
  • Page 71 Input7 Config Menu Exh Pres Flow SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Set Maximum Sensor Max The Sensor Max item is used to set the maximum reading 0 to + 1.00 in. W.C. 1.00 in. W.C. Sensor Pressure of a flow station and pressure transducer used to measure Output...
  • Page 72 Input7 Config Menu Exh Lin Flow SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Set Flow Station Duct Area The Duct Area item is used to program the cross sectional 0 to 50.00 ft 0.00 ft Duct Area area of the duct where the flow station is mounted.
  • Page 73 Input7 Config Menu Exh Lin Flow SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Set Minimum Signal Min The Signal Min item is used to set the minimum output 0 to 10 V Sensor Voltage signal when a flow station and pressure transducer is used Output to measure exhaust air flow Set Maximum...
  • Page 74 Input7 Config Menu Exh Venturi SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Maximum Flow Max Flow The Max Flow item sets the flow rate through the venturi 0 to 10000 cfm 0 cfm valve when it is fully open. The display will indicate a volumetric flow rate.
  • Page 75 Input7 Config Menu Exh Switch SOFTWARE DEFAULT MENU ITEM ITEM DESCRIPTION ITEM RANGE NAME VALUE Low Flow alarm Low Flow Sig The Low Flow Sig item sets the signal the Model RPC30 Open, Closed Close Signal Room Pressure Controller will receive to indicate a low exhaust flow condition.
  • Page 76 (This page intentionally left blank)

  • Page 77: Calibration

    Calibration The calibration section explains how to calibrate the controller and how to zero a TSI flow station pressure transducer (optional). The Model RPC30 controller will warn the user with a display message if it has not been calibrated. NOTE: This section assumes that the appropriate sensor has been correctly installed. Inaccurate readings may be detected if sensor is not installed correctly.

  • Page 78: Flow Calibration

    4. Select the SIGNAL MIN item and enter the minimum output signal of the transducer. In this example, you would enter 0 V. 5. Select the SIGNAL MAX item and enter the maximum output signal of the transducer. In this example, you would enter 10 V.
  • Page 79 e. Enter the actual flow measurement under the CALIBRATED FLOW menu item. Press the SAVE key to save the flow data. g. The low flow calibration is complete. 4. Enter the HIGH CAL item to perform the high flow calibration submenu with the following items: HIGH POS Damper position for high flow calibration...
  • Page 80 Venturi with Feedback Calibration NOTE: LOM Venturi Valves are optional and may not be installed in your system. 1. Obtain the venturi valve minimum and maximum flow, either by reading the label on the venturi valve or by performing duct traverses when the venturi valve is fully closed and fully opened.

  • Page 81: Optimizing Controller Performance

    3. Set the SENSOR SIG MIN to the minimum output voltage of the relative humidity sensor. This is usually 0 V. 4. Set the SENSOR SIG MAX to the maximum output voltage of the relative humidity sensor. This is usually 10 V. 5.

  • Page 82: Maintenance And Repair Parts

    activating PI control. If the SENSITIVITY setting is 60% (40% missing), the room pressure (velocity) must be 40 ft/min off set point before PI control is activated. Conversely, if the SENSITIVITY setting is 80% (20% missing), the room pressure (velocity) must only be 20 ft/min off set point before PI control is activated.

  • Page 83: Pressure Sensor Cleaning

    Pressure Sensor Cleaning Accumulations of dust or dirt can be removed with a dry soft-bristled brush (such as an artist's brush). If necessary, water, alcohol, acetone, or trichlorethane may be used as a solvent to remove other contaminants. Use extreme care when cleaning the velocity sensors. The ceramic sensor may break if excessive pressure is applied, if sensor is scraped to remove contaminants, or if the cleaning apparatus abruptly impacts the sensor.

  • Page 84: Hardware Test

    Software and hardware problems are covered in the troubleshooting chart. Pick the problem that most closely resembles your problem and review the possible symptoms and corrective action. Software or system performance problems can and are affected by the supply air system, exhaust air system, or physical configuration of the room.
  • Page 85 Figure 13. Flow Control screen in Diagnostics menu  Touch the Exhaust button to manually command the exhaust control device to a new position. If the RPC30 is not configured for Exhaust Control, the Exhaust button will display Bad Interface. AO1 Signal Type. ...
  • Page 86  Touch the Supply button to manually command the supply control device to a new position. If the RPC30 is not configured for Supply Control, the Supply button will display Bad Interface. AO2 Signal Type.  Room Temp, Supply Temp and Supply Flow measurements and input voltages will update in real time.
  • Page 87 Test - View Inputs Enter the View Inputs item to view all inputs with real-time updates. Figure 17. View Inputs screen in Diagnostics menu The Model RPC30 controller will display “Unconfigured” for any inputs that have not been  configured. Go to the Configure menu to configure these inputs appropriately. ...

  • Page 88: Troubleshooting Chart

    Troubleshooting Chart Symptom Possible Cause Corrective Action Display is blank. Fuse is blown. Measure voltage at pins 1 and 2 on DIM 2-pin connector. The voltage should nominally be: 15 to 40 VDC when powered from a TSI electric actuators. 24 to 30 VAC when powered from a transformer.
  • Page 89 Symptom Possible Cause Corrective Action Controller is not Incorrect wiring. Verify correct wiring (see Wiring diagram; Appendix C). DIM controlling. must be wired exactly as shown. DIM is in no If in no isolation mode, damper goes to preset position, flow isolation mode.
  • Page 90 Symptom Possible Cause Corrective Action Controller is not Defective Perform test described in Control system is not controlling. controlling variable If Flow Control is functioning, verify wiring to VFD by (cont.) frequency drive confirming control output voltage changes at VFD. If voltage (VFD).
  • Page 91 Symptom Possible Cause Corrective Action Incorrect Pressure sensor must be set for 0 to 10 volt output, not DIM always pressure sensor 4-20 mA (do not confuse this output with DIM analog displays output. output). Check pressure sensor DIP switch 3 and make 0.200 in.
  • Page 92 Symptom Possible Cause Corrective Action DIM does not Incompatible Data sent to DIM may be in form that the controller cannot respond to software. recognize. network communications. (cont.) ® LonWorks Contact factory for further assistance. board not installed. ® Bad LonWorks Contact factory for assistance.
  • Page 93 Symptom Possible Cause Corrective Action Displayed room Supply or Go to DIAGNOSTICS menu, FLOW CONTROL item to take pressure or flow Exhaust system manual control of the supply and exhaust control devices. If wildly unstable. room pressure stabilizes, supply or exhaust system is not fluctuating.
  • Page 94 (This page intentionally left blank) Part Two...

  • Page 95: Appendix A

    Appendix A Specifications* Digital Interface Module Display Range ........-0.20000 to +0.20000 in. W.C. (-50 to +50 Pa): TSI Sensor -1.00 to +1.00 in. W.C. (-250 to +250 Pa): Pressure Transducer Resolution ......... 5% of reading or 0.00001.0 in. W.C. (0.0025 Pa): TSI Sensor 5% of reading or 0.001.0 in.
  • Page 96 Outputs–Three (3)Total Output 1 ........Exhaust Control (0 to 10 VDC) Output 2 ........Supply Control (0 to 10 VDC) Room 1 Pressure Out, Exhaust Flow Out (0 to 10 VDC / 4-20 mA) Output 3 ........Temperature Control (0 to 10 VDC / 4-20 mA Anteroom Pressure Out, Exhaust Flow Out, Supply Flow Out (0 to 10 VDC / 4-20 mA) Alarm Contacts ......

  • Page 97: Appendix B

    Appendix B Network Communications Network communications are available on the PresSura room controllers. The PresSura room ® ® controllers can communicate with a building management system through Modbus , LonWorks or BACnet ® MS/TP protocols. Please refer to the appropriate section below for more detailed information.

  • Page 98: Network Points Ram Variables

    Network Points RAM Variables RAM variables use the Modbus command 04 Read Input Registers. RAM variables are read only variables that correspond to what is shown on Digital Interface Module (DIM) display. TSI offers a number of different models, so if a feature is not available on a unit, the variable is set to 0. Variable Information Provided to Master Variable Name...

  • Page 99: Xram Variables

    Modbus Communications (continued) XRAM Variables ® These variables can be read using Modbus command 03 Read Holding Registers. They can ® be written to using Modbus command 06 Write Single Register. Many of these variables are the same “menu items” that are configured from the controller keypad. The calibration and control items are not accessible from the DDC system.
  • Page 100 Variable Variable Name Address Read/Write Integer DDC system receives Input 6 Read Room 1 Temperature Configuration Anteroom Occupancy Sensor Anteroom Door Switch None Read Input 7 Room 1 Supply Air Temperature Configuration Exhaust Pressure Flow Exhaust Linear Flow Exhaust Venturi Exhaust Switch Anteroom Key Switch None...
  • Page 101 Modbus Communications (continued) Variable Variable Name Address Read/Write Integer DDC system receives Position Room 1 No Read/Write Flow Isolation Control Pressure Mode Room 1 No Read/Write If No Isolation Control Mode = Isolation Mode Position: Displayed in % Open Control Setpoint Flow: Displayed in cfm Pressure: Model RPC30 uses Room 1 Negative Mode Control Setpoint or...
  • Page 102 Variable Variable Name Address Read/Write Integer DDC system receives Exhaust Air Control Read/Write 0% to 100% Open Minimum Position Exhaust Air Control Read/Write 0% to 100% Open Maximum Position Anteroom Mode Read/Write Positive Negative No Isolation Anteroom not configured Anteroom Low Read/Write Disabled Alarm Enable...
  • Page 103 Modbus Communications (continued) Variable Variable Name Address Read/Write Integer DDC system receives Output 3 Signal Read None Type Room 1 Supply Flow Output Room 1 Exhaust Flow Output Anteroom Pressure Output Room 1 Temperature Control Output 3 Range Read If Pressure: Displayed in in. W.C. Host DDC system must divide value by 100 to report pressure correctly If Flow: Displayed in CFM...
  • Page 104 EXAMPLE of 03 Read Holding Registers function format: This example reads the Room 1 Room Mode and Room 1 Low Alarm Status. QUERY RESPONSE Field Name (Hex) Field Name (Hex) Slave Address Slave Address Function Function Starting Address Hi Byte Count Starting Address Lo Data Hi No.

  • Page 105: Lonworks ® Object

    ® LonWorks Object Node Object Network Variables SNVT Description SNVT Name SNVT Type Number nviRequest SNVT_obj_request nviTimeSet SNVT_time_stamp nvoStatus SNVT_obj_status nvoAlarm SNVT_alarm nciLocation SCPTLocation nciOutInHt SCTPalrmInbT nciIndex SCPTdevMajVer nciVersion SCPTdvMinVer Room Pressure Controller Object Network Variables SNVT Description SNVT Name SNVT Type Number Room 1 Setback Mode...

  • Page 106: Description Of Lon Snvts

    SNVT Description SNVT Name SNVT Type Number Number of Rooms nvoNumRooms SNVT_char_ascii Maximum Time Without Sending nciMaxSendTime SCPTmaxSendTime Update Minimum Time Before Sending nciMinSendTime SCPTminSendTime Update Room 1 Pressure Minimum Update nciSndDeltaP1 SCPTsndDelta Change SCPTsndDelta Room 2 Pressure Minimum Update nciSndDeltaP2 Change SCPTsndDelta...
  • Page 107 Model RPC30 BACnet MS/TP Protocol Implementation Conformance ® Statement Date: August 1, 2016 Vendor Name: TSI Incorporated Product Name: PresSura Room Controller Product Model Number: RPC30 Applications Software Version: 1.0 Firmware Revision: 1.15 BACnet Protocol Revision: Version 1, Rev 8 Product Description: TSI's PresSura controller is designed to maintain the room pressure differential of isolation rooms, operating rooms and other critical environments.
  • Page 108 Analog Value Object Yes  No Dynamically Create: Yes  No Dynamically Delete: Optional Properties: Reliability Writable properties: Present_Value, Out_Of_Service Proprietary Properties: None Property Range Restrictions: None Data Type: Real Binary Input Object Yes  No Dynamically Create: Yes  No Dynamically Delete: Optional Properties: Reliability, Active_Text, Inactive_Text...
  • Page 109 Data Link Layer Options:  BACnet IP, (Annex J)  BACnet IP, (Annex J), Foreign Device  ISO 8802-3, Ethernet (Clause 7)  ANSI/ATA 878.1, 2.5 Mb. ARCNET (Clause 8)  ANSI/ATA 878.1, RS-485 ARCNET (Clause 8), baud rate(s) ____________ ...

  • Page 110: Bacnet ® Ms/Tp Object Set

    BACnet MS/TP Object Set ® Writable Device Object Type Instance *Units Description Object Value Notes and Range Analog Input in. W.C., Pa Room1 Pressure Analog Input cfm, l/s, CMH Supply Flow Rate Analog Input Air Changes Per Hour Analog Input % RH Relative Humidity Analog Input...
  • Page 111 Writable Device Object Type Instance *Units Description Object Value Notes and Range Analog Value in. W.C., Pa Room 1 Pos Low 0.19500 to Alarm +0.19500 in. W.C.: TSI Sensor -1.0 in. W.C. to 1.0 in. W.C.: Pressure Transducer Analog Value in.
  • Page 112 Writable Device Object Type Instance *Units Description Object Value Notes and Range Analog Value cfm, l/s, CMH Occupied Mode 0 to 10,000 cfm Cooling Flow Analog Value cfm, l/s, CMH Unoccupied Mode 0 to 10,000 cfm Minimum Supply Flow Analog Value % Open Minimum Supply 0 to 100...
  • Page 113 Writable Device Object Type Instance *Units Description Object Value Notes and Range Binary Input Room 1 Occupancy 0 Occupied (Normal) 1 Unoccupied Binary Input Anteroom 0 Occupied (Normal) Occupancy 1 Unoccupied Binary Value Room 1 High Alarm 0 Disable 1 Enable Binary Value Room 1 Low Alarm 0 Disable...
  • Page 114 Writable Device Object Type Instance *Units Description Object Value Notes and Range Multi-State Room 1 Mode 1 Positive Value 2 Negative 3 No Isolation Multi-State ACH Duct 1 Supply Value 2 Exhaust 3 Off Multi-State No Isolation Control 1 Position Value Type 2 Flow...

  • Page 115: Appendix C

    Appendix C Wiring Information Back Panel Wiring Input / PIN # Output / Signal Description Comm 1, 2 Input 24 VAC/DC Power in Digital Interface Module (DIM). 24 V Power for TSI Pressure Sensors 24 VAC 3, 4 Output 0 to 10 VDC Input 1 5, 6 Input...
  • Page 116 WARNING Controller must be wired exactly as wire diagram shows. Making modifications to the wiring may severely damage the unit. Figure 20: Wiring Diagram –Through-The-Wall Sensor Wiring to Model RPC30 Appendix C...
  • Page 117 WARNING Controller must be wired exactly as wire diagram shows. Making modifications to the wiring may severely damage the unit. Figure 21: Optional Anteroom Through-The-Wall Sensor Wiring to Model RPC30 Wiring Information...
  • Page 118 Figure 22. Wiring Diagram – Pressure Transducer Sensor to Model RPC30 Appendix C...
  • Page 119 Figure 23. Optional Anteroom Pressure Transducer Sensor Wiring to Model RPC30 Figure 24. Optional Supply & Exhaust Flow Switch Wiring to Model RPC30 Wiring Information...
  • Page 120 Figure 25. Optional Supply & Exhaust Pressure-Based Flow Station Wiring to Model RPC30 Figure 26. Optional Supply & Exhaust Linear Flow Station Wiring to Model RPC30 Appendix C...
  • Page 121 Figure 27. Optional Supply & Exhaust Thermal Flow Station Wiring to Model RPC30 Figure 28. Optional Supply & Exhaust Venturi Valve Wiring to Model RPC30 Wiring Information...
  • Page 122 Figure 29. Optional Door Switch Wiring to Model RPC30 Figure 30. Optional Occupancy Sensor Wiring to Model RPC30 Appendix C...
  • Page 123 Figure 31. Optional Temperature Sensor Wiring to Model RPC30 Figure 32. Optional Key Switch Wiring to Model RPC30 Wiring Information...
  • Page 124 Figure 33. Optional Key Switch with Remote Alarm Wiring to Model RPC30 Appendix C...
  • Page 125 Figure 34. Optional Relative Humidity Sensor Wiring to Model RPC30 Figure 35. Optional Temperature Setpoint Wiring to Model RPC30 Wiring Information...
  • Page 126 24V IN 24V OUT INPUT 1 RELAY 1 RELAY 2 SENS COMM ALARM ALARM INPUT 2 INPUT 3 INPUT 4 INPUT 5 INPUT 6 INPUT 7 EXH CNTRL OUTPUT 2 OUTPUT 3 NURSE COMM BAC/LON/MOD TEMPERATURE SENSOR Figure 36. Optional Supply Air Temperature Sensor Wiring to Model RPC30 Figure 37.
  • Page 127 Figure 38. Optional Reheat Actuator Wiring to Model RPC30 Wiring Information...
  • Page 128 NO T ES A 120Ω resistor should be installed on both ends of the RS-485 loop. B is positive, A is Negative Figure 39. Wiring Diagram – Optional Nurses Station Communications Wiring to Model RPC30 Appendix C...
  • Page 129 NO T E A 120Ω resistor should be installed on both ends of the RS-485 loop. Figure 40. Optional Modbus and BACnet MS/TP Communications Wiring to Model RPC30 Figure 41. Optional LONworks Communications Wiring to Model RPC30 Wiring Information...
  • Page 130 Figure 42. Proper Communication Wiring Diagram Appendix C...

  • Page 131: Appendix D

    Appendix D Access Codes / Passcode The Model RPC30 Room Pressure Controller may prompt you to enter an access code to change the room mode or to enter the menu system. The access code screen is shown below in Figure 42. To enter the access code, type in the 4-digit passcode shown below and press Save. The PresSura room controllers feature two levels of passcode access: ...
  • Page 132 (This page intentionally left blank) Appendix C...
  • Page 133 TSI Incorporated – Visit our website www.tsi.com for more information. Tel: +1 800 874 2811 India Tel: +91 80 67877200 Tel: +44 149 4 459200 China Tel: +86 10 8219 7688 France Tel: +33 1 41 19 21 99 Singapore Tel: +65 6595 6388 Germany Tel: +49 241 523030...
