Stereo Inputs

If one of the Stereo Inputs is selected, the stereo signal is
routed to the 7.1 Speaker Outputs L and R.
Additionally you can add the Sub Out by pressing the LFE
button.
The Sub Out provides the full-range mono sum of the
left and right stereo signal. (Bass management is not
included.)
9
7.1 Inputs Stereo Inputs
1 2 1 2
L C R LFE
7.1 Speakers
E.g.: Stereo Input 1 is routed to the 7.1 Speaker Outputs L and R.
7.1 Inputs Stereo Inputs
1 2 1 2
L C R LFE
7.1 Speakers
E.g.: Stereo Input 1 is routed to the 7.1 Speaker Outputs L, R and Sub
Out.
I F R
Routing
Solo
In Place To C Mono L/R Alt
LS RS LB RB
Solo
In Place To C Mono L/R Alt
LS RS LB RB
Mute
Mute
