Outputs
DB25 ouput
•
DB25 (TASCAM-Standard)
•
Frequency range: 10 Hz to 150 kHz (-3 dB)
•
Crosstalk at 1 kHz: -92 dB
•
THD & N: 0.001 % (at 0 dBu, 1 kHz, 100 kohms load)
•
Noise (A-weighted): -93 dB
•
Dynamic range: 115 dB
XLR output
•
Neutrik XLR, balanced, Pin 2 = (+)
•
Frequency range: 10 Hz to 150 kHz (-3 dB)
•
Crosstalk at 1 kHz: -92 dB
•
THD & N: 0.001 % (at 0 dBu, 1 kHz, 100 kohms load)
•
Noise (A-weighted): -93 dB
•
Dynamic range: 115 dB
20
I
F R
Specifications
