1. Introduction

1.2. System Components

The EzSensor device installer should check the following items listed in the table below before system
installation. If the serial numbers of the individual parts do not match, do not install the system and contact
your local distributor or agent for support.
< Table 2. EzSensor Cable Connections >
No
Sensor Module
1.
2. Control Box
3. USB Cable (3M)
Holder for Control box
4.
Holder for Sensor
5.
EasyDent V4 Installation CD
6.
Driver Installation CD
7.
EzSensor Manual
8.
1. Sensor Module
Consists of a special CMOS sensor specifically designed for use in radiography and enclosed in a
hermetically sealed ergonomic capsule. The sensitive surface of the sensor is covered with a thin
layer of scintillating phosphorous through which X-ray radiation is converted into light and then into
an electric charge.
Components
7
Remark
USB 2.0 (Mandatory)
Document
