Hoisting and stowing Chair Topper

Technical specification

A
C
EN
Dimensions
A, length ...................................................... 143 cm
E
B, width ........................................................ 131 cm
C, height .............................................. 46+10* cm
D, extension .................................................91 cm
E, chain lenght ...109 cm
(200 cm with ext. kit)
F, max folded height .................................93 cm
G, max folded apex height .................. 83 cm
H, max folded width ................................35 cm
B D
Product data
F
Lift capacity .................................................... 20 kg
G
Unit weight ..................................................... 55 kg
Fuse auto reset................................................ 15A
Motors ..........................................................12VDC
Load cycle time ..........................................30 sec
All weights and dimensions are for reference only.
*During operation the product extends an additional
H
10 cm in height.
