Furinno FNAJ-11067 Assembly Instruction

STEP 4
4.1 Attach Door Panel(H),(G)with L/R Turn Plate(4),(5)using Screw(1).
4.2 Attach Door Panel(F)to the completed unit in Step 4.1.
** Repeat Step 4 to another 2 doors.**
STEP 5
5.1 Attach Door Panel to cabinet using Plastic Nut/Screw(6).
5.2 Attach Shelf Panel(G)to the center of Door Panel
using Screw(1).
** Repeat Step 5 to another 2 doors.**
(1) x2pcs
G
H
F
Recommended Maximum Weight
15
*Unit in Pound(lbs)
(1) x10pcs
G
H
F
G
(6) x2pcs
(6) x2pcs
Note: Attach Plastic Nut(6)to Plastic
Cover(9)through hole and tighten with
Screw(6).
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 45 minutes
Side Panel
Turn Plate
Plastic Cover
Recomm. 2 Person
Tool Required
www.furinno.com
Assembly Instruction
Furinno Rubik 3-Door Shoe
Storage Cabinet
MODEL :
DIMENSION :
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
FNAJ-11067
19.7"(W) x 40.8"(H) x 9.5"(D)
FNAJ1106720140414
