Furinno FNAJ-11073 Assembly Instruction

STEP 5
Attach Top Center Panel(F) to Large
Shelf Panel(D)and Top Panel(C).Tighten
Top Panel(C) to L/R-Side Panel(A),(B)
with Screw(1).
(1)x 4pcs
C
F
(2)x 4pcs
D
B
A
Recommended Maximum Weight
15
10
10
*Unit in Pound(lbs)
STEP 6
6.1 Cover Sticker(3)to the exposed screws
for neat appearance.
6.2 Hang the completed unit to the wall
with Wall Screw/Plastic Anchors(4).
You can hang it either horizontally
or vertically.
Wall
(4)x 2pcs
Back
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 30 minutes Approx. 20 minutes Approx. 15 minutes Approx. 5 minutes
Recomm. 2 Person Recomm. 1 Person
Tools Required Tool Required Tool Required
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno Boyate Magic Cube Five Grid
Storage Rack
FNAJ-11073
MODEL :
DIMENSION : 18.8"(W) x 35.4"(H) x 6.5"(D)
