STEP 3
3.1 Attach L/R Top Panel(A)to Center Top Panel(B)with Hinge(4).
3.2 Install L-Brackets(7)to Center Top Panel(B)and Center Panel(C)using Screw(1).
A
(4)x 4pcs
Recommended Maximum Weight
50
*Unit in Pound(lbs)
(7)x 2pcs
C
D
B
A
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 30 minutes
Recomm. 2 Person
Tool Required
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno Boyate Special Simple
Folding Table
FNAJ-11072
MODEL
:
DIMENSION :
35.4"(W) x 28.9"(H) x 23.6"(D)
FNAJ1107220140421
