2 - Installation

2.3.3 How to Temporarily Dock tDynamo

To temporarily dock the device in the docking stand for convenient charging, follow these steps:
1) If the docking stand will be mounted to a countertop, follow the steps in section 2.3.2 How to Mount
the Docking Stand to do that first.
2) Make sure the docking stand is connected to a USB host.
3) Make sure the device's docking stand contacts are clean and unobstructed.
4) Place the device all the way into the docking stand. The device powers on automatically and begins
charging.

2.3.4 How to Permanently Dock tDynamo

Do not leave the round key installed in the docking stand. The key is designed to be
removed to deter unauthorized removal of the device.
To permanently attach the device to the docking stand, follow these steps:
1) Make sure tDynamo is configured to use the docking contacts as its primary connection. If it is
configured to use another connection, use that connection first to change the configuration.
2) Follow the steps in section 2.3.3 How to Temporarily Dock tDynamo to place the device on the
docking stand.
3) Use the included round key to turn the locking screw on the back of the stand to lock the device in
place.
4) Remove the key and set it aside for future use, such as cleaning or servicing the device. It has a key
ring / string hanger loop integrated into its handle for convenience.
5) Make sure the device is firmly locked into the stand.
