Reference
Designation Description
A1 -approved
FCC
grammed circuit board assembly
A2 ETSI -approved
grammed circuit board assembly
A3 Head pcb assembly
MP 1 Gold-plated spring contacts
2 Actuators *old type*
MP
MP3 Actuator *current oval type*
Battery cup
MP4
Bezel * for older version handle *
MP5
MP6 Bezel *current oval type*
Handle *** Old version ***
MP7
MP8 Handle * Current type.* Uses oval
Bezel and Actuators. *** Must
replace Actuators and Bezel if
replacing from Old version handle
MP9 Kit contains: (2)Current type
Actuators, clip ring and (3)gold mic
contacts
Retaining Clip ring
MP10
MP11 Compression disk
J101 Battery snap (positive)
J102 Battery snap (negative)
Y201 Crystal
25C1018 (CC)
Shure T2 Vocal Artist Microphone Transmitter
Table 1
T2 Replacement Parts
Shure Part No.
pro- T90__8690
RF/Audio
[in the underlined space, insert the proper
frequency code-letters from Table 3 page 12,
—e.g., T90CA8690]
RF/Audio pro- T90__8705
[in the underlined space, insert the proper
frequency code-letters from Table 4 page 13,
—e.g., T90NE8705]
34A1090D
53F2039A
65A8225
65C8298
65A8206A
65B8207A no longer available
65B8299
65A8220A not available
65C8427A
RPW614
30A1314
38A180
56A317
56A318
40_8006A [in the underlined space, insert the
crystal-code from Table 3, page 12 (FCC) or
Table 4, page 13 (
31 Replacement Parts and Drawings
ETSI)]
