Planet WDRT-750AC Quick Installation Manual

Quick Installation Guide
WDRT-750AC
750Mbps 802.11ac Wireless
Broadband Router
1. Package Contents
Thank you for choosing PLANET WDRT-750AC. Before installing
the router, please verify the following items in the package box.
Wireless AP
Ethernet Cable 12V / 0.5A Power Adapter
If there is any item missing or damaged, please
contact the seller immediately.
Note
Step 2: Follow the figure below to connect the network
devices. It depends on your network environment
to connect the WAN port to a Cable/xDSL modem,
or the Ethernet directly in your place.
Phone Jack
RJ-11
RJ-45
Cable/xDSL
Modem
Quick Guide
– 1 –
PC/Laptop
RJ-45
Power Adapter
– 3 –
2. Hardware Installation
Step 1: Connect the Power Adapter provided in the package
CD-ROM
3. Network Configuration (Windows 7)
A computer with a wired Ethernet connection is required for the
first-time configuration of the Wireless Router.
Steps : Set your computer to get an IP address from the
1. Click "Start" button located in the lower-left corner of the
screen.
2. Click "Control Panel".
3. Double-click "Network and Sharing Center" icon.
4. Click "Change Adapter Settings".
5. Double-click "Local Area Connection" icon.
6. Select "Internal Protocol Version 4 (TCP/IPv4)" and
click "Properties" button.
7. Select "Obtain an IP address automatically" and
"Obtain DNS server address automatically", and
then click "OK" button twice to save the configuration.
Power
to the WDRT-750AC. The Power LED on the front
panel will turn on accordingly.
– 2 –
Wireless Router:
– 4 –
Power
Power Adapter
