GRAPHTEC Craft ROBO Quick Start Instructions page 2

1 1
The Craft ROBO has the two functions shown
below. Use them as required.
utting
Mounting the Cutter Plunger
Confirm that you have the following items supplied with your
Craft ROBO.
Cutter plunger
Blade adjustment cap
Blue (0.1 mm) Thin film
Yellow (0.2 mm) Thick film, thin paper
Red (0.3 mm) Thick paper such as a postcard
Cutter blade
Attach a blade adjustment cap.
Loosen
Tighten
Referring to the figure shown below, firmly mount the cutter
plunger in the Craft ROBO.
OPEN : Unlock
CLOSE : Lock
CLOSE
OPEN
Insert firmly into position
until this surface contacts
LOCK LEVER
the plunger holder.
The most suitable blade adjustment cap is automatically displayed
when the Media Type is selected in the Craft ROBO Controller.
Media Type selected to be cut
The most suitable cap color
for the selected Media Type is
displayed
Learn how to use it with the Media Trial Kit.
Operation Manual
heck
Plotting
Mounting
the Ball-point Pen
Referring to the figure shown below, mount a ball-
point pen in the Craft ROBO. When using a ball-
point pen, select "Pen" for "Media Type" in the
Craft ROBO Controller.
When using a ball-point
pen, be sure to use a
narrow one. In addition,
Ball-point pen
confirm that the tip of
plunger
the pen protrudes 3 to
3.5 mm from the ball-
point pen plunger. Please
refer to the Craft ROBO
User's Manual (CD-
ROM) for further details
Align with
on the ball-point pen
the notch
types that can be used.
Caution:
Be particularly careful with the cutter blade when
changing the blade adjustment cap or attaching
the cutter plunger to the Craft ROBO.
NOTE:
Graphtec does not guarantee the cutting quality
when non-genuine Craft ROBO media is used.
Using non-standard media may void the warranty.
2 2
Load a Sheet for Cutting or Check Plotting
Load a sheet in the Craft ROBO
Note before using
Do not load media without a protective liner, or perform a cutting operation when
there is no media loaded, as this will damage the cutting mat.
Press the standby switch, and confirm that the LED lamp lights.
While making sure that the sheet is straight, align it with the
guide line.
Turn the feed knob counterclockwise to feed the sheet.
Continue feeding the sheet until its top edge is aligned with the
cutting mat as shown below.
Feed knob
Setup is complete
Note: Turn the feed knob to remove the sheet.
When cutting has been completed, press the standby switch and confirm that the LED lamp goes out.
Notes on Loading Media in the To cut a sheet smaller than A4 size or a sheet without a
Craft ROBO protective liner, affix it to the carrier sheet included with the
Craft ROBO before performing cutting.
Sheet Width: 210 mm up to To cut regular A4-size
a maximum of 260 mm
media, peel off the
protective liner from both
When loading edges of the carrier sheet
prior to use.
Cutting Width: an A4-size
190 mm
sheet, align it
(max. 200 mm)
with the guide
The standoff ring should be used when cutting a sheet that
line.
has been affixed to the carrier sheet.
LED lamp
Standby switch
Align the sheet with
the guide line
Cutting mat
Turn the feed knob until
the sheet reaches the
edge of the cutting
mat.
Peel off this part prior to use.
Protective liner
Adhesive
Paper backing
Standoff ring
