7

Technical data

Description Unit
U V
DC
P W
max
m g (lb)
RF f = 868.3 ...
869.5 MHz [EU]
T °C ( °F)
amb
IP-class
φ
% RH
Wi-Fi f = 2.4 GHz
Zigbee f = 2.4 GHz
mm (inch)
Table 2
8

Maintenance and faults

8.1

Reset

If EasyControl no longer functions correctly:
▶ Lift the EasyControl briefly from the wall plate ( fig. 7, page 5).
If the problem persists:
▶ Press the Reset button ( fig. 20) and hold for several seconds.
Please note! This means that all personalised settings are deleted,
and the Wi-Fi connection must be established again.
If the problem persists:
▶ Consult the installer or manufacturer.
Fig. 20 Reset
8.2

Faults

The fault displays for the heat source are visible on the touch screen and
are sent automatically from the controller to the EasyControl app.
Contact with the installer can be selected in the app.
There is an extensive list on the EasyControl site with solutions for any
problems with EasyControl that may arise
1) See the back of this document for the web address.
EasyControl – 6720884199 (2018/01)
Value
14.3 – 16.0
0.9
250 (0.551)
(P = max. 13.4 dBm)
0 ... 45 (32 ... 113)
IP30
10 ... 90
IEEE 802.11b (P = max. 17 dBm)
IEEE 802.11g (P = max. 14.1 dBm)
IEEE 802.15.4 (P = max. 14.6 dBm)
h = 153 (6)
w =103 (4)
d = 24 (1)
1)
Controller.
Fault Remedy
No Wi-Fi connection. The Wi-Fi signal for the Wi-Fi
router may be too weak. Install a Wi-Fi amplifier.
Wi-Fi network The "Hide" function for the Wi-Fi router is possibly
not found switched on, or the "Broadcast" function (sending
SSID) may be switched off. Temporarily switch off the
"Hide" function or switch on the "Broadcast" function.
No connection to the Internet server. Wait until the
connection to the Internet server has been
automatically restored. Even without a server
connection, the heat source can be controlled in
manual operation or via the time program after it has
been put into operation.
Forgotten The serial number and access code are on the sticker,
serial number which is on the front of the brief installation
and access instructions, and on the sticker at the back of the
code EasyControl. If the app is used to log on, the serial
number and access code can be displayed in the app,
by navigating via the "Info menu" to the "Product
information" submenu. If the serial number and access
code can not be found, please contact "Consumer
1)
Info" .
The app has no Does the EasyControl have a connection to the
contact with Internet ( section 5.4)? Serial number and access
the code entered? Please note, these are capital letter
EasyControl sensitive. There is possibly a slow Internet connection.
Wait for a few minutes.
The displayed The displayed temperature can be set in the app or on
temperature the EasyControl site
is too high or
too low
The touch If the touch screen does not detect anything for more
screen does than 5 minutes, it automatically switches itself off.
not function After this, the touch screen can only be activated again
by touching it.
Password with EasyControl uses the standard Wi-Fi protocol. Do not
$ character therefore use any $ characters in the Wi-Fi network
password. Remove the $ character from the network
password.
App is not fully It is possible that, when delivered, the EasyControl
functioning does not yet have the current software version. This
means that possibly not all app functions can be used.
The software update occurs automatically and make
take some time.
Indication of one of the following messages: repeated
ignition attempts, dripping/leaking DHW tap, too little
flow through the heating system, leak in the heating
system, boiler pressure too low, or heat source shows
the Maintenance symbol. These are informative
signals. The heat source is functioning normally.
The heat source is malfunctioning. Go to the
EasyControl app for more information.
No software Software updates are performed automatically.
updates have This requires a continuous Internet connection.
been received If the router is provided with a timer, updates can be
from missed.
EasyControl
Table 3 Fault overview (the symbols are displayed on the touch screen)
