Summary of Contents for Magnavox MHT935BT
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Before using the unit, be sure to read all operating instructions carefully. Please note that these are general precautions and may not pertain to your unit For example, this unit may not have the capability to be connected to an outdoor antenna. -
Page 4: Power Source
POWER SOURCE Connect the small plug from the supplied AC/DC Adaptor to DC IN Jack on the rear of unit. Connect the AC/DC TO DC IN JACK Adaptor to a wall outlet having AC 100-240V~, AUX IN 2 DC IN 12V,2A POWER ON OFF... -
Page 5: Location Of Controls
LOCATION OF CONTROLS AUX IN 2 DC IN 12V,2A POWER ON OFF AUX IN 1 AUX IN 2 DC IN 12V,2A POWER ON OFF AUX IN 1 1. Remote Sensor（On the front of unit） 2. POWER ON/OFF Switch 3. DC IN Jack (DC 12V, 2A, 4. -
Page 6: Location Of Controls (Remote Control)
LOCATION OF CONTROLS (Remote Control) ON/OFF AUX 1 AUX 2 RESET TUNE- TUNE+ VOL - VOL + (Standby) Button 7. TUNE - / (Skip Backward) Button 2. � (Mute) Button 8. TUNE + / (Skip Forward) Button 3. LED ON/OFF Button 9. -
Page 7: Battery Installation (Remote Control)
BATTERY INSTALLATION (Remote Control) During first time use, slide the insulation film out from the battery tray and discard it as illustrated to the right: When the battery is consumed, replace the battery as shown below: 1. Push the tap on the battery tray and slide it out as the illustrated below: 2. -
Page 8: General Operation
OPERATION GENERAL OPERATION: 1. Connect the supplied AC/DC Adaptor to the unit and wall outlet as previously instructed. 2. Slide the Power ON/OFF Switch on the rear of unit to turn the unit to standby mode. 3. Press the (Standby) Button on the unit approximately 2 seconds then release the button or (Standby) Button on the Remote Control to turn the unit ON from standby mode. - Page 9 Notes: When the external BT Device searche the unit, our model number “MHT935BT” will appear on the display of external BT Device. If while pairing you are asked for a code please try "0000" or "1234".
- Page 10 FM Radio: Power on the unit as previously instructed. Press the SOURCE – LED ON/OFF Button on the unit repeatedly until the STANDBY/FM Indicator is illuminated and blink. Or, press the FM Button on the Remote Control to enter FM Radio mode directly, the STANDBY/FM Indicator will illuminate and blink.
- Page 11 AUX 1 1. Insert one of the plugs from supplied Audio connection cable (with 3.5mm stereo mini plugs) to the Phones Jack; Line Out Jack or AUX Out Jack on external audio device such as iPhones; iPad; iPod; MP3 Player; Discman … etc as shown below. 2.
-
Page 12: Troubleshooting Guide
TROUBLESHOOTING GUIDE Check the follows before requesting service: SYMPTOM POSSIBLE CAUSE POSSIBLE SOULTION No power AC/DC Adaptor had not Connect the AC/DC Adaptor to wall outlet the wall outlet and unit connect to and unit POWER Switch is in OFF Slide the POWER ON/OFF Switch position on the rear of unit to ON... -
Page 13: General Specifications
GENERAL SPECIFICATIONS Power Source: ………………………………DC 12V, 2A, Centre Positive Power Source of Remote Control: ….DC 3V, 1 x CR 2025 Button Cell (Included) Power Consumption: ………………………………………………………….. Max. 24 Radio FM Band Coverage: …………………………………………….…. 87.5-108MHz BT Effective Range: ........…………..Up to 32 Feet in open area Remote Control Effective Range: ……………………………Up to 12 Feet in open area Audio Power: …………………………………………………………….. - Page 14 LIMITED WARRANTY...
