Summary of Contents for Magnavox MHT833
- Page 1 WATERPROOF PORTABLE SPEAKER SYSTEM with Decorative Color Changing Lights ® and Bluetooth Wireless Technology OWNER'S MANUAL PLEASE READ BEFORE OPERATING THIS EQUIPMENT. MODEL: MHT833 Size: 148.5(W) x 210(H)mm (A5)
- Page 2 The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product`s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
- Page 3 Portable Cart Warning...
- Page 4 17) Overloading Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock. 18) Object and liquid entry Never push objects of any kind into the product through openings as they may touch dangerous voltage points or short out parts that could result in fire or electric shock.
-
Page 5: Power Source
POWER SOURCE The unit has a built in Sealed Lead Acid rechargeable battery, recharge it before use or when it is drained as follows: 1.Make sure the unit is in Standby or Power on mode. Otherwise, press the POWER ON-OFF Switch to ON position to power on the unit to standby mode. -
Page 6: Top Panel
TOP PANEL POWER MODE MIC VOLUME MIC ECHO GT VOLUME LIGHT VOLUME FRONT VIEW SIDE PANEL 1A OUT DC IN 1. MIC VOLUME (Microphone Volume) Control Knob 2. MIC ECHO (Microphone Echo) Control Knob 3. GT VOLUME (Guitar Volume) Control Knob (Play/Pause) Button POWER 5. - Page 7 OPERATIONS: General Operation: 1. Recharged the built in battery as previously instructed. 2. Press the Power ON/OFF Switch to ON position on the right of unit to turn the unit to standby mode. The POWER Indicator on the top of unit will illuminate. /MODE Button on the top of unit approximated 1 second until “ON”...
- Page 8 BT MODE: BT (Bluetooth) pairing: First time use or re-pairing the unit to a new BT Device, pair as follows: 1. Power on the unit and enter to BT mode as previously instructed. “bt” will appear on the display and blink. 2.
- Page 9 FM (Radio): Search and play the FM station: 1. Power on the unit as previous procedures. 2. Press the MODE/ Button on top of the unit repeatedly until the FM frequency appears on display. " " 3. Press the Button to search and play the desired station manually. or press and hold the Button to search the available station, when a station searched, the unit will stop seraching and play the station.
- Page 10 Microphone: 1.Connect the supplied Microphone to the MIC Jack as the figure below: 1A OUT DC IN Dynamic Microphone Included POWER SIDE FUNCTION PANEL 2. Power on the unit and play the music as usual. 3. Slide the ON/OFF Switch on the Microphone to ON position to turn on the Microphone. 4.
- Page 11 USB: 1. Insert the USB Device into the USB port as the figure below: 1A OUT DC IN USB Device NOT Included POWER SIDE PANEL 2. Power on the unit and play the music as usual. 3. Press the MODE/ Button on top of the unit repeatedly until the USb appears on display.
-
Page 12: Troubleshooting Guide
Retractable Handle: Press the button on the top of the handle to release the lock then pull it out or back as the illustrated figure below: TROUBLESHOOTING GUIDE Check the follows before requesting service: SYMPTOM POSSIBLE CAUSE POSSIBLE SOULTION No power Power Switch is in OFF Press the POWER ON-OFF Switch position... - Page 13 Cleaning: 1. To prevent fire or shock hazard, disconnect your unit from the AC/DC Adapter when cleaning. 2. The finish on your unit may be cleaned with a dust cloth and cared for as other furniture. Use caution when cleaning and wiping the plastic parts. 3.
-
Page 14: Limited Warranty
This product has been manufactured by and is sold under the responsibility of Craig Electronics Inc, and Craig Electronics Inc is the warrantor in relation to this product. MAGNAVOX and SMART. VERY SMART are registered trademarks of Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V. -
Page 15: Fcc Notice
FCC NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
