Easidew PRO XP User's Manual
1
INTRODUCTION
The Easidew PRO XP has been manufactured, tested and calibrated to the highest
available standards and should arrive in perfect working order, ready for installation into
a gas or liquid measurement application.
For questions about the instrument or how to install and operate it, contact your local
representative. Refer to www.michell.com for details of Michell Instruments' worldwide
offi ces' contact information.
There are two variants of the Easidew PRO XP, each available with various options for
display, housing, range, etc.:
Easidew PRO XP-TX
Easidew PRO XP-LQ-TX
1.1
Features
The Easidew PRO XP is a continuous, on-line, 4-20 mA transmitter for the measurement
of moisture content in air, other non-corrosive gases and non-polar liquids. It is designed
specifi cally for use within Zone 1 & 2 and Zone 21 & 22 Hazardous Areas (ATEX &
IECEx) and Class I, Division 1, Groups A, B, C & D, Class II and III, Division 1, Groups
E, F & G, Class I, Zone 1 & Zone 21 Hazardous Locations ( N. America). See appendix
A and B for further details.
The Easidew PRO XP key features are:
•
Measurement ranges -110 up to +20°Cdp (-166 to +68°Fdp)
•
Global explosion / flameproof certification
•
Accuracy ±1°Cdp (±1.8°Fdp)
•
2-wire 4-20 mA output
•
Traceable 13-point calibration certificate
•
450 bar (6526 psi) pressure rating
•
3/4" UNF industry standard process connection
•
EN 10204 3.1 material certification
•
Moisture in gases and liquids
•
Optional integral display meter
•
Aluminium or stainless steel enclosure
Michell Instruments
For gases
For liquids
INTRODUCTION
1
