MICROPHONE

GENERAL DESCRIPTION

Designed for both hand-held and stand mounting uses, the TOA DM-1300US is a unidirectional microphone suited for
speech and vocal applications. The microphone body is rigidly constructed of diecast-zinc, and is designed to reduce
switching and handling noise.
APPEARANCE

SPECIFICATIONS

Model
Type
Directivity
Rated Impedance
Rated Sensitivity
Frequency Response
Mated Connector
Weight
Dimensions
Talk Switch

Finish

Standard Accessory

Specifications are subject to change without notice.
DM-1300US
Moving coil microphone
Unidirectional
600
, balanced
-54 dB (1 kHz, 0 dB = 1 V/Pa)
70 Hz ~ 15 kHz
XLR-3-11C or equivalent
245 g
51 X 170 mm
Short-off circuit type, slide switch
Body: Zinc-diecast, painted Metallic gray
Head: Steel and Zinc plated steel wire, painted Metallic gray
Microphone holder (W5/8")
TOA Corporation
INSTRUCTION MANUAL
DM-1300US
CIRCUIT DIAGRAM
