9. Press 1
10. Set CV
11. Press 2
12. Set CV
13. Press 2 again (to indicate that you don't want to add a new step). You are done with recording. If you wanted
to continue the sequence, you would have pressed 3, set a CV, press 4, set a CV, and press 4 (the sequence
length is limited to 8 steps).
Edges' is digitally calibrated. Please follow this procedure to calibrate all channels:
1. Unplug all jacks connected to the GATE,
2. Set all the FREQ potentiometers to their central position.
3. Connect the note CV
channel's V/OCT input. Because all
calibrating the other channels.
4. Hold the channel 1 WAVEFORM SELECT
5. The LEDs show this pattern: **oo, to indicate that you need to play a C2 note (CV equal to 1V). Once the note
has been played, press switch 4 to continue.
6. The LEDs show this pattern: ****, to indicate that you need to play a C4 note (CV equal to 3V). Once the note
has been played, press switch 4 continue. The channel is now calibrated.
7. Repeat the steps 4/ 5/ 6/ 7/ by holding the channels 2, 3 and 4
This product is covered by Mutable Instruments' warranty, for one year following the date of manufacture.
This warranty covers any defect in the manufacturing of this product. This warranty does not cover any
damage or malfunction caused by incorrect use - such as, but not limited to, power cables connected
backwards, excessive voltage levels, or exposure to extreme temperature or moisture levels.
The warranty covers replacement or repair, as decided by Mutable Instruments. Please contact our
customer service (support@mutable-instruments.net) for a return authorization before sending the
module. The cost of sending a module back for servicing is paid for by the customer.
Mutable Instruments encourages modding and hacking, but we will not service modified units or provide
any assistance in the realization of mods.
Mutable Instruments | Edges
V/OCT
output of a well-calibrated keyboard interface or MIDI->CV converter to the first
V/OCT inputs are normalled, this signal will also be available for
switch until LEDs 3 and 4 blink. Press switch 4 (calibration).
and FM inputs.
WAVEFORM SELECT
4 of 5
switches.
