Installation
Kinks requires a
-12V / + 12V power supply
(2x5 pin connector).
The ribbon cable connector
must be aligned so that the
red stripe of the ribbon cable
(-12V) is on the same side of
the module's power header as
the "Red stripe" marking on
the board. The module draws
25mA from both the +12V and
-12V supply rails.
Kinks happily accepts both
Kinks
audio and CV signals.
Mingling and
Online manual and help
mangling
The full manual can be found
online at:
mutable-instruments.net/mod-
ules/kinks/manual
For help and discussions, head to:
mutable-instruments.net/forum
Please refer to the online manual
for detailed information regarding
compliance with EMC directives
Advertisement
Related Manuals for Mutable Instruments Kinks
Summary of Contents for Mutable Instruments Kinks
- Page 1 “Red stripe” marking on the board. The module draws 25mA from both the +12V and -12V supply rails. Kinks happily accepts both Kinks audio and CV signals. Mingling and Online manual and help mangling...
- Page 2 Analog AND (minimum, Rectifier and inverter troughs) output. Try this with envelopes or LFOs, or to create new wave- shapes from VCO outputs. Input signals Signal input. Sample&hold and Inverted output. white noise Half-wave rectified output. The negative half of the signal is clipped to 0V.
