Mutable Instruments Edges Manual

Advanced channel settings
1s
Select a channel by holding the channel selection button
for 1 second.
Quantization
Calibrate
ON/OFF
Sequencer
Record
ON/OFF
Enable/disable the quantizer or sequencer playback,
start sequencer recording, or start the calibration pro-
cedure.
After modifying the settings, hold any one of the 4
switches for 1 second to exit the advanced channel
settings mode.
Calibration
1. Set the FREQ potentiometer to its central position
and unplug any cable from the MOD inputs. Connect a
precision CV source (such as a MIDI>CV interface) to
the V/Oct input of the channel to calibrate.
2. Hold the waveform selection switch of the channel to
calibrate. Leds 3 and 4 blink.
3. Press 4 to start calibration.
4. Two LEDs are lit. Play a C2 note (CV of 1V). Press 4.
5. Four LEDs are lit. Play a C4 note (CV of 3V). Press 4.
The channel is calibrated!
Quantization
Each channel includes a semitone quantizer. The
quantizer can be enabled/disabled with switch 1 in the
channel settings mode.
Sequencer
A sequence of 8 notes can be recorded and played back
by each channel.
While a sequence is playing, changing the frequency
(panel control or CV) transposes the sequence. The
sequence is clocked by the GATE input.
Terry Riley disapproved of the concept of a RESET input.
Recording a sequence
Hold one of the 4 WAVEFORM SELECT switches to select
the channel in which you want to record a sequence.
Leds 3 and 4 will blink.
Press 3 to start recording. Led 1 lights on to indicate the
active step (step 1). Set the FREQ control on the selected
channel to the desired note; or enter a note from your
CV keyboard or through your MIDI-CV interface.
Press the second switch to continue to the next step.
Set the FREQ control on the selected channel to the
desired note for the second step. Press the third switch
to continue, etc. To stop recording, press the currently
active step.
For example, to record a 6 note sequence: set the CV,
press 2, set the CV, press 3, set the CV, press 4, set the
CV, press 1, set the CV press 2, set the CV, and press 2
again to finish.
1 2 3 4
5 6
Edges
quad chiptune audio generator
